Fanuc Horizontal Automatic Cnc Lathe Machine Price CK6140 CNC Machine Manufacturers
US$ 6000.00 - 15.00
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
hankui
Place of Origin:
Shandong, China
After-sales Service Provided:
Engineers available to service machinery overseas
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port/Shanghai port/other port in china
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Performance Horizontal Cnc Lathe Automatic CK6180 Alloy Wheel Repair Brass Cnc Turning LatheUS$ 22000.00 - 15.00MOQ: 1 Set -
Economical Cnc Automatic Lathe Boring Bar Holders CK6150 Cnc Precision Automatic Lathe Cnc Milling MachineUS$ 12000.00 - 15.00MOQ: 1 Set
-
Heavy Duty CNC Universal Milling Machine With Gearbox PartsUS$ 26,900 - 39,100MOQ: 1 Set
-
Industrial CNC Milling And Drilling Machine Engraving MachineryUS$ 26,900 - 39,100MOQ: 1 Set
-
Micro CNC Engraving Milling And Drilling Cut MachineUS$ 26,900 - 39,100MOQ: 1 Set
Brand Name
hankui
Place of Origin
Shandong, China
After-sales Service Provided
Engineers available to service machinery overseas
Condition
New
fanuc Horizontal Automatic cnc lathe machine price CK6140 CNC machine manufacturers
Product Description
Detailed Images
Technical parameters
| Item | Unit | CK6136 | CK6136A | CK6140 | CK6150 |
| Max.Swing over bed | mm | 360 | 360 | 400 | 500 |
| Max.Swing over slide | mm | 200 | 200 | 230 | 300 |
| cessing Length | mm | 750 | 500/750 | 750/1000 | 1000/1500/2000 |
| Guideway width of bed | mm | 280 | 350 | 350 | 390 |
| X axis travel | mm | 210 | 210 | 220 | 250+10 |
| Z axis travel | mm | 750 | 500/750 | 750/1000 | 750/1000/1500/2000 |
| X/Z axis lead screw | 2505/3206 | 2505/3206 | 2505/3206 | 2505/4010 | |
| X/Z axis Rapid speed | m/min | 6/8 | 6/8 | 6/8 | 6/8 |
| X/Z axis positioning precision | mm | 0.02/0.03 | 0.02/0.03 | 0.02/0.03 | 0.02/0.03 |
| X/Z axis repositioning precision | mm | 0.012/0.016 | 0.012/0.016 | 0.012/0.016 | 0.012/0.016 |
| Processing precision | IT6-IT7 | ||||
| Ellipticity | 0.01 | ||||
| Surface Rouhness | Ra≤1.6 | ||||
| Spindle Speed Range | Two steps,80-400-2000 | 50-3500 | 50-3500 | 60-200.200-650.650-1600 | |
| Spindle head type | ISO A2-6/D6 | A2-6 | A2-6 | C-5,C-8,D-8 | |
| Dia.of Spindle Thru-hole | mm | 52 | 56 | 66 | 82(105) |
| Spindle Hole Tapper | mm | MT6 | MT6 | MT6 | 105mm,1:20 |
| Chuck | mm | 200(8") | 200(8") | 200(8") | 250 |
| Spindle Motor power | kw | 5.5 | 5.5 | 5.5 | 7.5(three steps frequency) |
| Tool Holder Type | Vertical 4 stations (Horizontal 6 stations) | ||||
| Turning tool size | mm | 25*25 | 25*25 | 25*25 | 25*25 |
| Tailstock Sleeve travel | mm | 100 | 120 | 120 | 150 |
| Tailstock Sleeve Dia. | mm | 52 | 60 | 60 | 75 |
| Tailstock Sleeve Taper | mm | MT4 | MT4 | MT4 | MT5 |
| CNC control system | 1)SIEMENS; 2)FANUC; 3)KND; 4)GSK; 5)MITSUBISHI; 6)Syntec; |
||||
| N.W | kgs | 1700/2000 | 2100/2300 | 2200/2500 | 2600 |
| Dimension | mm | 2100*1100*1700 | 1900*1100*1700 | 2500*1700*1700 | 2600*1200*1700(750mm) |
