SINOLINKING Knelson Centrifugal Concentrator Gold Separating System

Name: SINOLINKING Knelson Centrifugal Concentrator Gold Separating System
Brand: SINOLINKING
Price: USD $2,353 - 5,990 / Set

FOB Price

USD $2,353 - $5,990 / Set

1 Set(Min.Order)

Supply Ability 311 Set / Sets per Month
Port Qingdao Seaport China
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	SINOLINKING	Place of Origin:	Shandong, China	Model Number:	SLK-C60
Certification:	ISO9001 BV SGS	After-sales Service Provided:	Engineers available to service machinery overseas
Warranty:	12 months	Weight:	500 kg	Dimension(LWH):	1180x1140x1250mm
Production Capacity:	high	Voltage:	110 V-380 V	Condition:	New
Power(W):	1.5 KW

Product Description

SINOLINKING Knelson Centrifugal Concentrator Gold Separating System

Why choose us?

1-Established in 2002,13 years OEM experience, first Knelson concentrator manufactured in China.

2-Individual-customized design, All-inclusive machine, one shop, full set processing line.

3-Stationary or portable up to your choice.

4-Processing capacity from 30tons to 300tons per hour.

5-Engineers available for overseas installation and training.

6-Turn-key operations available.

7-Worldwide shipping.

8-Long life, heavy-duty equipment.

9-Reliability, less down time and more profits.

10-Pay less money and recover more gold than other machines.

FAQ

1. Are you factory?
---Yes, we are direct factory with an area of over 30,000m^2.
2. How big are you?
   -----We have 4 workshops covering 4,000m^2, office over 2000m^2, 65 workers.
3. What equipment do you build?
   ----Gold/diamond wash plants, gold/diamond dredgers, centrifugal concentrators, etc.
4. What’s the capacity of your equipment?
   ---From 5ton per hour to 450 ton per hour.
5. What kind of engine/generator do you use?
   ---We use Cummins brand, or Weichai brand. Or as required by clients.
6. What warranty do you give for your machine?
   ---We supply free spare parts for wearing parts.
   ---We give 12-18 months warranty for main parts.
   ---We provide lifelong maintainence and technical support.
7. Do you have a website?
---Yes. or
---You could also watch our machinery working videos on our YouTube channel:
/channel/UC-Vf9UTJ3LU7ANC2l0LmpOQ

Product Description

What's the details about our Concentrator Gold ?

Knelson Gold Concentrator is a new type of gravity concentration equipment for gold separating and other high density minerals. The centrifugal machine has many competitive advantages compared with other concentration machines which create high returns for the investors.

We have fully-automatic (Knelson Continuous Variable- Discharge, CVD type) and semi-continuous(Batch type) centrifugal gold concentrators.

Since 1985, three models of centrifugal concentrator have been developed. Application shows that the recovery can be as high as 99%, especially for the case in recovering the natural gold in lode ore with 65% of the ore having a milling size of0.074mm, the recovery for the natural gold is expected up to 98%. For that natural gold of 0.004mm in particle size, the recovery is 97%. The cleaning up cycle is 1~4 hours. And the upgrade ratio is up to 1,000 times.

Features:

1) High recovery rate: Through our test, the recovery rate for placer gold can be 98% or more, for rock gold, the recovery rate could reach 97% when the feeding size is below 7mm.

2) Easy to install: Only a small leveled place required. It's a full line machine, before starting it, we only need to connect the water pump and power.

3) Easy to adjust: There are only 2 factors that will affect the recovery result, they are water pressure and feeding size. By giving proper water pressure and feeding size, you could get the best recovery effect.

4) No pollution: This machine only consumes water and electric power, and exhaust tailings and water. Low noise, no chemical agent involved.

5) Easy to operate: After finishing the water pressure and feeding size adjust, clients only need to recover the concentrates every 2-4 hours. (Depending on the grade of the mine)

General Parameters

What 's the general parameters about our Concentrator Gold ?

Type	SLK20	SLK30	SLK60	SLK80	SLK100	SLK120
Capacity(T/H)	0.25-0.30	2-3	10-15	35-40	40-60	80-100
Feeding Size(mm)	0-3	0-4	0-6	0-6	0-6	0-6
Feeding Concentration (%)	0-50%	0-50%	0-50%	0-50%	0-50%	0-50%
Back Wash Water (T/H)	1.5-2	4-6	10-15	17-25	40-60	100-120
Output(kg/time)	2-3	10-20	30-40	60-70	70-80	80-120
Power(kw)	0.75	1.5	4	15	22	30
Revolution	800	600	460	400	360	360
Pressure Water (M Pa)	0.04	0.1	0.16	0.18	0.2	0.2
Outline (mm)	790x785x790	1180x1140x1250	1970x1670x1750	2300x1800x2200	2500x2000x2400	2500x2200x2500
Weight(kg)	300	500	1300	1800	2800	4500

Please note the parameters are for your reference only. We shall design the best processing line for you after knowing your mining situation.

Detailed Images

Would you like to know more details about our Concentrator Gold ?

SLK-MGT series mobile gold trommel wash plant with different gold recovery system:
Click the photo to find more details about it:

Working Videos

Woud you like to watch our machinery working videos now on YouTube channel?

Gold trommel wash plant	/playlist?list=PLveqQLNek0LuXyyt2wZkDWfiUjTaKTq0w
SLK-MGT50 Madagascar:	/playlist?list=PLveqQLNek0Lt-nYwTT1dh-QHhSBktiWVm
Centrifugal Concnetrator	/playlist?list=PLveqQLNek0LvZ38dpAKRtvfnbVXAqG52p
Gold/Diamond Dredger:	/playlist?list=PLveqQLNek0Lt1C2oVvZOg-fWbmyQfqflv
Gold recovered by clients	/playlist?list=PLveqQLNek0Ls4cBfz3dkI-3JlpFOFP1dF
Vibrating deck wash plant	/playlist?list=PLveqQLNek0Lu2nlXiFKfvjZXV3UkP3Wks

Packaging & Shipping

Whats the packing and shiping about our gold wash plant?
