Polycarbonate sheet Product Standard&Technical Parameters
Thickness(mm) | Weight(kg/m²) | Minimum bending radius(mm) | Minimum span | Transparency(%) | Sound insulation(db |
| 4 | 0.9 | 70 | 1500 | 83 | 14 |
| 6 | 1.3 | 1050 | 2000 | 82 | 17 |
| 8 | 1.5 | 1400 | 2700 | 81 | 18 |
| 10 | 1.7 | 1750 | 3300 | 79 | 19 |
| 12 | 1.9 | 2100 | 3600 | 76 | 20 |
Technical Parameters
Impact strength | Transparency | Specific gravity | Coefficient of thermal expansion | Service temperature | Heat conductivity |
2.1j/m-2.3j/m | 40%-80% | 1.2g/cm³ | 0.065mm/m °C | -40°C-120°C | 3.0-3.9w/m2°C |
Tensile strength | Flexural strength | Modulus of elasticity | Effect of sound insulation | Tensile stress at break | Elongation at break |
≥60N/mm | 100N/mm² | 2400Mpa | 10mm two laminates reduced 10 db | ≥65Mpa | >100% |
| capacity for 20 GP | 2.1m*5.8m*4mm | 600sheet |
| 2.1m*5.8m*6mm | 400sheet | |
| 2.1m*5.8m*8mm | 300sheet | |
| 2.1m*5.8m*10mm | 240sheet | |
| 2.1m*5.8m*12mm | 200sheet |
| capacity for 40GP | 2.1m*5.8m*4mm | 1200sheet | 2.1m*11.8m*4mm | 600sheet |
| 2.1m*5.8m*6mm | 800sheet | 2.1m*11.8m*6mm | 400sheet | |
| 2.1m*5.8m*8mm | 600sheet | 2.1m*11.8m*8mm | 300sheet | |
| 2.1m*5.8m*10mm | 480sheet | 2.1m*11.8mm*10mm | 240sheet | |
| 2.1m*5.8m*12mm | 400sheet | 2.1m*11.8m*12mm | 200sheet |
| capacity for 40HQ | 2.1m*5.8m*4mm | 1350sheet | 2.1m*11.8m*4mm | 675sheet |
| 2.1m*5.8m*6mm | 900sheet | 2.1m*11.8m*6mm | 450sheet | |
| 2.1m*5.8m*8mm | 674sheet | 2.1m*11.8m*8mm | 337sheet | |
| 2.1m*5.8m*10mm | 540sheet | 2.1m*11.8m*10mm | 270sheet | |
| 2.1m*5.8m*10mm | 450sheet | 2.1m*11.8m*12mm | 225sheeet |
Polycarbonate sheet has the following characteristics:
(1) light: light transmission rate of up to 89%, which can be compared with the glass.
(2) impact resistance: the impact strength is 250-300 times of ordinary glass, 30 times of the same thickness of acrylic board, 2-20 times of fiber glass.
(3) anti UV: one side has the anti-ultraviolet ray (UV) coating, the other side with anti condensation coating.
(4) light weight: the proportion is only half of the glass, saving the cost of transportation, unloading, installation, and supporting framework.
(5) flame retardant: national standard GB50222 - 95 confirmed that the PC sheet is B1 level.
(6) flexibility: at the site it can be bent coldly.
(7) sound insulation: sound insulation effect is obvious.
(8) energy saving: in summer keep cool, in winter keep warm.
(9) the temperature adaptability: it does not have the cold brittleness at -40℃, and not soften at 125℃.
(10) anti condensation: outdoor temperature of 0℃, indoor temperature of 23℃, the indoor relative humidity less than 80%, inner surface has no condensation.
(11) simple and convenient, not as heavy as traditional materials.
| packaging | Both sides with PE film, the end with paper tape. Other package are available based on customers' requirement. |
| delivery | 7-30 days after receipt of deposit. |
Mr Luis Liu
Mobile: +86 158 536 38730 Whatsapp: +86 158 536 38730 Wechat: 158 536 38730 or SD-Sinobeacon Email: sinobeacon(a) QQ: 2294750285 Add: Zhaode South Road, Qingzhou, Weifang City, Shandong, China |
1. How long is the delivery time? |
According to your order quantity, the delivery time is usually 7-60days. |
2. How long is the warranty period? |
Different sheet have different warranty, and different warranty has different price.usually the polycarbonate sheet warranty period is 1-5years. |
3. Is your compay foreign trade company or manufacturer? |
we are both. |
4. Can you supply sample? |
| Small parts can be supplied, but you should pay the express. |
5. Can your company supply greenhouse design? |
Our company can give greenhouse design according to your land and plan after deposit. And we can give simple drawing before signing contract. |
6. can you supply installation service? |
If you need, we only send engineers, and you match local workers. If you think it is hard to do, we also can send engineers and workers to install for you. |
7. When installing, what cost should we pay? |
our engineers and workers visas and round-trip tickets, their foods and accommodation, their communication |
8. What is the payment terms? |
usually the deposit is 30%-50% of total value. Before loading, all the balance shoulde be paid off. Or you can give your own payment terms, then we can negotiate it. |
