10T MIine Use large construction dump truck
- 0 per Month
- Qingdao
- T/T Credit Card
You May Like
Product Details
Brand Name | Map Power | Place of Origin | Shandong, China | |
Condition | New | Transmission Type | Automatic | |
Gross Vehicle Weight | 3500 | Fuel Type | Diesel | |
Emission Standard | Euro 3 | Drive Wheel | 4x4 | |
Dimensions (L x W x H) (mm) | 7300X2400X3630mm | Engine Capacity | 4 - 6L | |
Capacity (Load) | 1 - 10t |
Product Description
10T MIine Use large construction dump truck
As a low-volume, short-distance transport of bulk materials for small site dumpers, because of its easy operation, small turning radius can be used in a narrow environment, etc,. Dumpers are widely used in many different occasions, such as the construction industry, the factory floor, battlefield ,protecting road section, the municipal engineering, underground mines and so on.
There have two different model of 10Ton site dumper.
FCY100 normal model,FCY100R which the bucket can have a 180 degree rotate in any direction.
FCY100---10Ton site dumper Normal model | |
| |
FCY100R---10Ton site dumper with 180 rotate burket | |
|
NO. | Item | Specifications | ||||||
1. | Payload | 10000kg | ||||||
2. | Operating weight | 9850 kg | ||||||
3. | Hopper capacity | 4.5 m3 | ||||||
4. | Maximum speed | 25-30 km/h | ||||||
5. | Handbrake available on grade | 25% | ||||||
6. | Max grade ability | 25% | ||||||
7. | Distance of road after brake | ≤2.5m with load and speed 10km/h | ||||||
8. | Minimum turn radius | 4.5 m | ||||||
9. | Ground clearance | 248 mm | ||||||
10. | Noise level | ≤106 db(A) | ||||||
11. | Loading discharge angle | 48.40 | ||||||
12. | Time of discharge | 8 s | ||||||
13. | Hydraulic pressure | 16 Mpa | ||||||
14. | Wheel base | 2000 mm | ||||||
15. | Wheel tread | 1580 mm | ||||||
16. | Engine power | 92KW OR 97KW | ||||||
17. | Dimensions (L x W x H) | 7300X2400X3630MM | ||||||
B. Engine | ||||||||
| ||||||||
1. | Model/Maker | DEUTZ TD226B or CUMMINS engine | ||||||
2. | Type | Diesel 6 cylinders direct fuel injection, water cooled | ||||||
3. | Rated Power | 92KW or 97KW | ||||||
4. | Speed | 2400 R/Min | ||||||
C. Drive System | ||||||||
1. | Brand | JINGYI | ||||||
2. | Transmission: | Power shift 4Forward and 2 reverse gears | ||||||
3. | Drive shaft: | Tubular-type, open-type, rigid needle-bearing universal joint | ||||||
4. | Driving axle: | Main drive type: single-stage hyperbolical bevel gear dive | ||||||
D. Frame | ||||||||
1. | Frame: | Channel steel welding type, two-section articulated connection | ||||||
2. | Tire: | 23.5/70-25 | ||||||
E. Steering system
F. Bake system | ||||||||
1. | Operating brake | Hydraulic shoe system, four-wheel brake | ||||||
2. | Handbrake | mechanically-pirated central sport-type disc | ||||||
G. Hydraulic system | ||||||||
1. | Hydraulic pump: | Gear pump | ||||||
H. Electric system
| ||||||||
Battery | 24V |
1.Why chose you?
site dumper | wheel loader | Automobile crane |
Excavator | Backhoe loader | forklift |
Weifang Yishan Heavy Machinery Co., Ltd is a professional manufacture of wheel loaders,dumpers,tractors,implements and whole solution supplier specializing in construction machinery and agricultural equipment.
We can also design new products according to customer and market demand.We have more than 10 years experiences in professional manufacturing.And successfully sold equipment to around 40 countries and areas.We sincerely welcome customers and friends all over the world to visit our factory and cooperate with us in future.
(Director And Sale Manager)
Email:tina at
MOB:008618353638651
Website:
Skype:shen4570105
Whatsapp/Viber/:+8618353638651
Wechat:+8618053683138
