Home > Products > Backhoe loader > WZ30-16 backhoe best price in india, multifunction backhoe loader
WZ30-16 backhoe best price in india, multifunction backhoe loader
- Qingdao China
- T/T Credit Card
You May Like
-
WZ30-25 hot sales backhoe loader with cheap price
-
WZ30-25 mult-ifunctions frond end loader and backhoe loader
-
WZ30-25 construction machinery front loader and backhoe loader with CE certificate
-
MAP WZ30-16 backhoe best price in india, backhoe loader
-
Agriculture WZ30-25 Chinese brand backhoe loader for sales
-
China good quality but low price Backhoe loader 30-25
Product Details
| Brand Name | MAP | Place of Origin | Shandong, China | |
| Model Number | WZ30-16 | Type | Backhoe Loader | |
| Certification | CE and ISO9001 | After-sales Service Provided | Engineers available to service machinery overseas | |
| Warranty | 1 Year | Condition | New | |
| Dimension(Long * Breadth * High) | 5100X1960X2900mm | Moving Type | Wheel Loader | |
| Rated Load | 1600kg |
Product Description
WZ30-16 used bachoe loader, new backhoe loader
Main features:
Cab is bigger and more elegant than common backhoe loaders. We adopt laminated safety glass to have a wider and brighter space and also to make view more wider. The cab is with three doors, and can tilt forward by hydraulic system for convenient maintain.
2. Position of oil tank is reasonable, it is very easy to fuel up.
3. Adopt famous brand hydraulic parts, long service life and stable performance.
4. Adjustable seat, operation is convenient and operator will feel comfortable on the seat.
5. The cab is with air conditioner to make air in cab fresh.
6. Hydraulic steering system make operation easier. Hydraulic walking system with domestic best gear pump can realize stepless speed change.
7. Both have the all abilities of loader and excavator.
8. Work efficiency is high because of superior machine performance.
9. Can select other attached accessories, such as snow shovel plate, sweeper, breaking hammer, clamp equipment to meet customer’s different requirements.
Here is the specification of WZ30-16
Item | Unit | Parameter | |
Total Length | mm | 5100 | |
Total Height | mm | 2900 | |
Total Width | mm | 1960 | |
Total Operating Weight | kg | 4900 | |
Backhoe Parameter | Rated Backhoe Bucket Capacity | m3 | 0.3 |
| Max. Digging Depth | mm | 3400 |
| Max. Digging Height | mm | 5000 |
| Max. Digging Radius | mm | 4600 |
| Turning Angle of Movable Arm | ° | 180 |
Loading Parameter | Rise Height | mm | 3700 |
| Discharge Height | mm | 2700 |
| Min. Turning Radius | mm | 4800 |
| Discharge Distance | mm | 1000 |
| Rated Loading Weight | kg | 1600 |
| Rise Time of Movable Arm | s | 3.5 |
| Fall Time of Movable Arm | s | 2.5 |
| Comprehensive Time | s | 7 |
Engine Model | YUNNEI 490T | ||
Rated Power of Engine | KW | 42 | |
Engine Flux | ml/r | 40 | |
Work Pressure | Mpa | 16~18 | |
Max. Grade Ability | % | 25 | |
Walking Speed | km/h | 18~28 | |
Min. Ground Clearance | mm | 260 | |
Wheel Base | mm | 2000 | |
Tread | mm | 1530 | |
Tire model | mm | 20.5-16 | |
The backhoe loader will be well fixed in container.
Weifang MAP Import and Export Co,Ltd . was founded in 2006.We are a professional manufacture and chain supplier specializing in construction machinery and agricultural equipments.70% of our products are made for export.We keep diverse products according to customer and market demand.We produce and supply truck crane, site dumpers,wheel loaders, tractors,implements, wheel excavators, crawler excavators,backhoe loaders,forklifts,road rollers,light towers,concrete mixers,plate compactor,impact tampers, road cutters,concrete vibrators,and so on.
Any question,just feel free to contact me .
