Help CenterHOT!! China 956 Hydraulic Compact Wheel Loader
Related Products
-
Good Quality!! 3T 4x4 LS939 Hydraulic Mini Wheel LoaderUS$ 22,990 - 24,919MOQ: 1 Unit -
Good Quality 4x4 1.5T Articulate Mini Wheel Loader PriceUS$ 9,250 - 11,350MOQ: 1 Unit
-
ZL06F CE Multifunctional 4WD Garden Mini LoaderUS$ 5,000 - 6,500MOQ: 1 Unit
-
3 Cylinders Engine Good Quality 906 Wheel LoaderUS$ 6,000 - 6,700MOQ: 1 Unit
-
China Compact 5T ZL50 Wheel Loader With ShovelUS$ 43,080 - 48,990MOQ: 1 Unit
Real Factory directly Supplies Wheel Loader Series, Customer Design is Welcome and Available.
Main Descriptions for Mini Wheel Loader Series
- Antirust paint with all color, streamlined appearance, beautiful and elegant, and can attach different tools such as: coal bucket, pipe fork, grass fork, stone bucket… to realize multifunction. Wildly used building site, coal mines, brickyard, stone materials factory, urban construction and so on.
- Bucket that can be set level automatically, "Z" type turning bucket structure, to realize the enormous shovel digging forces.
- Dual pump meeting hydraulic system can economize on oil 10%,
- Central articulated frame and load sensing hydraulic steering gear, short turning radius and flexible turning, can work in narrow site and has sound off-road performance, good traffic ability and larger traction.
- Cabin made by double-layer1.4mm steel plate with strong steel frames inside.
- A fully enclosed cabin and the seats have the functions of vibration reduction and easy adjustment from 4-6 directions, offers the driver a comfortable and wide view.
Specification |
ZL50F |
Rated capacity |
3m³ |
Rated weight |
5000Kg |
Operating weight |
16000Kg |
Performance of bucket being set level |
Yes |
Static tilting load at full steering position |
98KN |
Max. breakout force |
172.6KN |
Max. drawbar pull |
151.9KN |
Max. grade ability |
30° |
Total of three time:lifting,dumping, lowering |
11.3s |
Max.dump height |
3098mm |
Max.dump reach |
1198mm |
Min. ground clearance |
450mm |
Wheel base |
3200mm |
Overall dimensions(length*width*height) |
7836*3010*3300mm |
Engine |
STEYR |
Model |
WD10G220E22 |
Pattern |
Inline, water cooled, direct. inject, four strokes |
Cylinder-bore*stroke |
6-126*130 |
Max.torsion |
779Nm |
Rated power |
162KW |
Min.fuel consuming rate |
214g/kw.h |
Specified rotational speed |
2200r/min |
Model of torque device |
YJ375 |
Pattern |
3-element,single stage |
Number of great shift |
4 forward,4 revers |
Max. travel speed |
38km/h |
Main reducer type |
Spiral bevel gear, moderation of first stage |
Pattern of wheel side moderation |
Single stage planetary |
Type size |
23.5-25 |
Front type pressure |
392KPa |
Rear type pressure |
343KPa |
Pattern |
Articulated and hydraulic steering, load sensing meets |
Steering angle(each direction) |
35°C±1 |
Min. turning radius(outside of bucket) |
7268mm |
Valve distributing working |
DF32·2C |
Working pumps |
CBG3100 |
Brake system |
Air assisted oil type four wheel brake |
Parking brake |
Air cutting control inner expand hoof |
Fuel capacity |
320L |
Pressure of working hydraulic system |
160kfg/cm2 |
Pilot Control
Quality Assurance
- Have established and implemented a standard procedure for quality management system and product certification.
- QA/QC inspectors work independently form the production lines
- Keep its supplier assessment reports and be traced by lot identification to the appropriate raw material test reports
- A procedure to conducting random inspection after final packaging.
- A clear procedure for handling customer feedback. “7 Days Guarantee” for customer renewing the consumable accessories.
- Tool case and partly consumable accessories attached with shipment meanwhile
- After-sales and Quality Warrant Contact for every purchase order.
Company Profile
WeiFang Map Power is well-known constructional & agricultural machinery and implements exporter since 2007, and we have our own real factory- WeiFang YiShan Heavy Machinery Co., Ltd, which located in “China Machinery Town” – WeiFang city. The owners of these two companies are couplers. Our main business is as following:
1. Wheel Loader Series, rated loading weight from 800kgs to 5T,such as:
Mini Type: D25, ZL06, ZL08, ZL10, ZL12,CS915,ZL16,
Middle-sited Type: WZ30-25, ZL20, CS920, ZL30,ZL50, ZL60, ZL70 etc.
2. Farm Tractor Series,
3. Site Dupers series
4. Constructional equipments, farm tools and consumable parts of all kinds. Such as pallet fork, log grapple, snow plow, hole digger, sweeper, wood chipper, lawn mover, plough, rotary tiller…etc.
With the experience in professional manufacturing and international trade, Map Power has successfully expanded our business to about 30 countries including Canada, America, Russia, Australia and west Europe and Mid-Asia etc.
Hope to have a long and good cooperation with you.
