Help CenterHydraulic Transmission Wheel Loader Zl08 Best Price--Hot Sale!!
Related Products
-
Good Quality!! Multi-function CE Mini Wheel Loader ZL16FUS$ 10,492 - 10,820MOQ: 1 Unit -
Chinese Wheel Loader With Deutz Engine for SaleUS$ 18,000 - 24,919MOQ: 1 Unit
-
6 Ton Cheap China Loader for Sale in ChinaUS$ 30,000 - 50,000MOQ: 1 Unit
-
ZL30 Deutz Engine Middle-sized Hydraulic Wheel Loader With CEUS$ 22,990 - 24,919MOQ: 1
-
Latest Export Wheel Loader zl 20US$ 13,535 - 14,427MOQ: 1 Unit
Wheel loader *2 cylinders engine
Wheel loader *with different attachment
Wheel loader *Hydraulic quick change
Multifunction Wheel Loader ZL08F
4X4 Wheel Drive
Wheel loader ZL08F Specifications | ||
Engine Details |
Model |
CZ2102 |
Engine type |
In-line arrangement, water-cooled , 2 Cylinders diesel Engine |
|
Rated Power |
25KW |
|
Rated Speed |
2200 r/min |
|
Min.ful consumption |
235 g/kw.h |
|
Bucket |
Bucket Capacity |
0.40 m3 |
Bucket type |
Heavy-duty bolt on teeth |
|
Rated Loading weight |
800 kg |
|
Total Weight |
2200 kg |
|
Overall Dimensions |
Overall Length |
4050 mm |
Overall Height |
2550 mm |
|
Overall Width |
1600 mm |
|
Max. discharge height |
2300 mm |
|
Wheel base |
1580 mm |
|
Tread |
1400 mm |
|
Operating Specifications |
Steering System |
Articulated Frame with Hydraulic steering |
Min Turning Radius |
3900 mm |
|
Transmission |
Manual clutch |
|
Brake System |
Service Brake |
Four Wheel Hydraulic spread-shoed brake |
Parking Brake |
Hand operated |
|
Tire |
8.25-16 |
|
DETAILED PHOTOES
1. About our Company: Weifang Map Import&Export Co., Ltd.,was founded in 2006.We are a professional manufacture and chain supplier specializing in construction machinery and agricultural equipments,such as wheel loaders,site dumpers, farm tractors and wheel excavators.We have been exporting more than 8 years.We know very clearly of this market. And we believe that after 8 years,we still be there,to offer you the good quality machine!
2. About our Products: Our products are specially for global export market, with advanced configuration, good quality spare parts, streamlined and beauty appearance. The engine brand, transmission systems, electrical systems, axle, seals and many others are all choose in good quality supplier. In addition, our machine have very good finshing quality, because of our experienced engineers and workers, you can visit our factory to check all the details.
3.About our Delivery time: Our normally delivery time is within 25 working days, while most of the time, we could finish them in advance. In addition, some products are in storage of our factory, so urgent order will also be accepted.
4.About our Shippment: Factory direct delivery ,Very very careful inspection, then packing, then shipping. Our goal is solving the problems in factory, then you can trustworthy use. You should know that some suppliers only ship the machine to you, they do not care whether the machine is right or not.
About our after-sales service:
1).Our factory supply 1 year warranty for our machines, and will take responsibility for the whole life. For maintenance spare parts, we promise to send to you within 7 work days.
2).Easy-damaged part swill be prepared for you. To make sure your normal usage. Usually,these easy-damaged ones can operation 2000h because of our good job. So i think this is very important for your consideration.
3).We provide parts service at least 5 years after export date, We promise life-long services and offer you the free consulting service. Any question any time,you can feel free to contact us.We will be very happy to help you.
Hydraulic transmission wheel loader zl08 best price--Hot sale!!
