Hydraulic 4WD boom backhoe loader ZL16B
quick hitch wheel loader Performance Features
- The wheel loader uses a hydro-mechanical transmission which can make full use of engine power and can have an automatic variable transmission according to the external resistance. It avoids power failure of the engine due to the suddenly increased external load. The wheel loader can absorb and eliminate the vibration and impact of external load on engine. It protects the drive system and engine, increases the service life, facilitates the operation and achieves higher economical and production efficiency.
- The wheel loader uses a central articulated frame and load sensing hydraulic steering gear. The machine can achieve a short turning radius and superposition of the front and rear tracks upon turning (this will ensure safe driving.)The wheel loader has the advantages of easy operation on narrow sites, flexible operation, safety, convenient maintenance and so on.
- The wheel loader uses four-wheel drive, low-pressure wide base off-road tires and an oscillating rear axle, so it has sound off-road performance, good traffic ability and larger traction.
- The wheel loader is equipped with a single-pipe type hydraulic four-wheel brake.
- The wheel loader has a fully enclosed cab and the seats have the functions of vibration reduction and easy adjustment. The machine offers the driver a comfortable drive and wide view.
Detailed specification of ZL16F wheel loader:
|
Mini Wheell Loader Specifications (1.6T wheel loader) Overall Dimension | |||
1 |
Length(with bucket on ground) |
4900(mm) |
|
2 |
Bucket width |
2070(mm) |
|
3 |
Height(To the top of the cab) |
2740(mm) |
|
4 |
Wheel base |
2150(mm) |
|
5 |
Tread |
1500(mm) |
|
6 |
Min. ground clearance |
342(mm) |
|
Main Technical Specification | |||
1 |
Rated load |
1600(Kg) |
|
2 |
Operating weight |
4300KG |
|
3 |
Rated bucket capacity |
1.0(CBM) |
|
4 |
Max. breakout force |
45KN |
|
5 |
Max. dump clearance |
2850(mm) |
|
6 |
Dump reach |
960(mm) |
|
7 |
Dump angle at any position |
≤40 |
|
8 |
Digging depth(with bucket bottom horizontal) |
146(mm) |
|
9 |
9 Max. turning radius |
|
|
|
(1) Outside of bucket |
4850(mm) |
|
(2) Outside of rear wheel |
4675(mm) |
||
10 |
Pivot angle frame |
38+ |
|
11 |
Oscillating angle of rear axle + |
±11° |
|
12 |
Lifting time of bucket |
≤5.9(sec.) |
|
ZL16F mini wheel loader 4 wheel drive, hydraulic operation
ZL16F mini wheel loader with CE certification
ZL16F mini wheel loader can be with joystick, quick hitch, 4 in 1 bucket, road sweeper, snow blade, snow blower, snow bucket, pallet forks and so many other implements to achieve many different applications for customer
The related auxiliary equipment:
Customers:
Useing
Certificate
Our factory
Our Team
1 Packaging Details: wheel loaders are nude packed, well fixed, accessories are available. 3units/40'HQ
2 Delivery Detail: 20 workdays after receipt the wheel loader deposit
Advantages to work with us:
1)A professional international sales team, which enable us to turn inquiries into final products and export them to numerous countries and regions without barriers;
2) A well managed quality control system to customize on clients requirements. We can design according to customers usage invironment.
3)Unparalleled after sales service
FAQ
1. How to order?
-After you decide to purchase, we will send you proforma invoice with our bank information, bring this PI to the bank, and ask to make T/T for the deposit. For single set, your machine can be ready within 26 days after we getting the deposit, we will send to the port and deliver to you by sea.
-In case for more handling charges, you can transfer 100% of the payment, we can arrange the products and shipping under your allowance.
-If you still don't understand, please do not hesitate to ask me.
2. Related products?
ZL06F ZL08F ZL10F ZL12F ZL15F ZL16F ZL20F
3. How do we visit you and your factory?
-First of all, welcome you or any appointed agent to vist and inspect our factory.
-You can fly to Shanghai airport, then come from Shanghai railway station to Weifang city. (3 hours)
-You can fly to Qingdao airport, then come from Qingdao railway station to Weifang city. (45 minutes)
-We can pick up you at Qingdao airport or Weifang railway station.
-Please kindly let us know your schedule in details, so that we can arrange everything for you.
5. Why you choose us?
-As manufacturer, our products have excellent quality and competitive price.
-Good after-sales services and 24 months warranty are visible.
-Strictly testing and checking before shipping.
-7 years experience in manufacturing and 7 years exporting experience in Alibaba and Made-In-China.
6. How to contact with me?
-Sales director: Areil Yu
-Mob: 86 15966077053
-Address: Office add: R 2007 rongguanhuafu B Kuiwen, Weifang, Shangdong, China
Factory add: Shanshui Road,Changle,Weifang,Shangdong,China
