2ton industrial compact wheel loader ZL20F with famous engine optional
- 500 Set / Sets per Month
- Qingdao
- T/T Credit Card
-
0.8ton small mini front loader ZL08
-
China cheap mini compact loader with trencher, mini farming loader
-
2.0ton front loader, wheel loader, construction machine
-
1.0ton Skidsteer Loader with Snow Blade
-
0.8ton mini loader, 0.8ton mini tractor, mini agricultural equipment
-
0.8ton mini loader, 0.8ton garden tractor, 0.8ton front loader
Product Details
Brand Name: | MAP | Place of Origin: | Shandong, China | Type: | Mini Loader |
Certification: | ce, CE | Warranty: | 1 Year | ||
Condition: | New | Dimension(Long * Breadth * High): | 5600X2100X2850MM | Moving Type: | Wheel Loader |
Product Description
2.0ton industrial compact wheel loader ZL20F with Cummins engine optional
1)Dumping height:3100mm
2)Loader Bucket :1.2CBM
3)17/16-20 Tire
4)Joystick and Pilot control
Features new komatsu small cheap tcm wheel loader
*Fully hydraulic steering,power shift hydraulic operated working device.
*The full hydraulic steering system is smooth in operation, stable and reliable in performance
*Optional attachments like pallet fork,grass fork,snow blade and snow buckets available to all materials.
*High boom lifting capacity for heavy duty handing jobs.
*The bucket is equipped with automatic leveling device, so that the operation is easier.
*Big tractive force and traction device at the rear end, which meet more needs.
Detailed Specification:
Performance | 1 | rated loading | 2000kg |
2 | overall weight | 5800kg | |
3 | rated bucket capacity | 1.2m3 | |
4 | maximum tractive force | 54KN | |
5 | maximum breakout force | 45.4KN | |
6 | maximum grade ability | 30 | |
7 | maximum dump height | 3000mm | |
8 | maximum dump reach | 752mm | |
9 | overall dimension (L×W×H) | 5600×2100×2850mm | |
10 | minimum turning radius | 5251mm | |
Engine | 11 | model | 4105 |
12 | type | Vertical, in-line, water cooled, 4-stroke diesel engine | |
13 | No. of cylinder-bore/stroke | 4105×125mm | |
14 | rated power | 58kw2200r/min | |
15 | maximum torque | 270N.m | |
16 | min fuel-consume ratio | ≤243g/kw.h | |
Transmission system | 17 | torque converter | YJ280A |
18 | gearbox mode | Countershaft power-shift | |
19 | gear shift | 2 forward shift 2 reverse shift | |
20 | maximum speed | 24km/h | |
Drive axles | 21 | main reducing spiral
| Circular Arc Bevel gear, single stage |
22 | decelerating mode | Single stage planetary type | |
23 | wheel base (mm) | 2400mm | |
24 | wheel tread | 1640mm | |
25 | ground clearance | 310mm | |
Hydraulic system | 26 | system working pressure | 16MPa |
27 | boom lifting time | 4.8s±0.2s | |
28 | total time | 9.2s±0.5s | |
29 | fuel tank capacity | 80L | |
30 | function of leveling automatically | yes | |
Brake system | 31 | service brake | air assist disc brake on 4 wheels |
32 | parking brake | flexible shaft operated external drum | |
Tyre | 33 | type specification | 16/7020 |
34 | front tyre pressure | 0.22Mpa | |
35 | rear tyre pressure | 0.18Mpa |
Why choose us? |
Main Features of WEIFANG Map Power :
1. more than 10 years production experience
2. own a super technical team, can finish some adjustment to adapt the using environment and the market
3. production capacity: 300 units/month
4. our site dumper are exported to many developed countries, and satisfied the customers
5. One hour reaches Qingdao port.
6. All the inquiries will be replied within 12 hours
Attachments avaliable
Warranty and payment term
1) Payment terms: 30% T/T deposit,balance before shipment.
2) Delivery time: 25-30 days after we receive the deposit
3) Warranty period:1 year or 2000 working hours which comes first.
Company Contact Information
Contact :Tony
| Company Name: | Weifang Map Import & Export Co., Ltd. |
| Operational Address: | Room 1-2-2007, No. 8580, Dongfeng East Street, Kuiwen Dist., Weifang, Shandong, China |
| Telephone: | 0086-536-8502890 |
| Website: | |
| Website: | |
| website: |
Packing:Nude packing
Shipping: 2sets in 40HQ
1. How to order?
-After you decide to purchase, we will send you proforma invoice with our bank information, bring this PI to the bank, and ask to make T/T for the deposit. For single set, your machine can be ready within 26 days after we getting the deposit, we will send to the port and deliver to you by sea.
-In case for more handling charges, you can transfer 100% of the payment, we can arrange the products and shipping under your allowance.
-If you still don't understand, please do not hesitate to ask me.
2. Related products?
ZL06F ZL08F ZL10F ZL12F ZL15F ZL16F ZL20F
3. How do we visit you and your factory?
-First of all, welcome you or any appointed agent to vist and inspect our factory.
-You can fly to Shanghai airport, then come from Shanghai railway station to Weifang city. (3 hours)
-You can fly to Qingdao airport, then come from Qingdao railway station to Weifang city. (45 minutes)
-We can pick up you at Qingdao airport or Weifang railway station.
-Please kindly let us know your schedule in details, so that we can arrange everything for you.
4. Why you choose us?
-As manufacturer, our products have excellent quality and competitive price.
-Good after-sales services and 24 months warranty are visible.
-Strictly testing and checking before shipping.
-10 years experience in manufacturing and 10 years exporting experience in Alibaba and Made-In-China
