Specifications
Front wheel loader 4WD, CE, ZL08
rated load 800kg,
bucket capacity 0.40CBM,
mechanical drive
Weifang Map Power Co., Ltd., was founded in 2006. We are a professional manufacture and chain supplier specializing in construction machinery and agricultural equipments.70% of our products are made for export. We keep diverse products according to customer and market demand. We produce and supply site dumpers, wheel loaders, tractors, implements, wheel excavators, crawler excavators, backhoe loaders, forklifts road rollers, light towers, concrete mixers, plate compactor, impact tampers, road cutters, concrete vibrators, and so on.
Features:
1. The ZL08 wheel loader has a high-reliability gear box, drive axle and brake system.
2. With the high-reliability engine, the wheel loader can lower the oil consumption, noise and emissions.
3. The wheel loader uses the hard structural parts and powering working device to strengthen the excavating force.
4. The wheel loader employs the advanced hydraulic system and rigid steel structure.
5. Adjusting the swing angle of high and rear axle, the wheel loader can smooth the operations in narrow spaces or on rugged sites and so on.
Detailed facture:
Specification
Wheel loader ZL08F Specifications | ||
Engine Details |
Model |
Changchai L28 |
Engine type |
In-line arrangement, water-cooled , Single Cylinders diesel Engine |
|
Rated Power |
28HP |
|
Rated Speed |
2200 r/min |
|
Min.fuel consumption |
235 g/kw.h |
|
Bucket |
Bucket Capacity |
0.40 m3 |
Bucket type |
Heavy-duty bolt on teeth |
|
Rated Loading weight |
800 kg |
|
Total Weight |
2200 kg |
|
Overall Dimensions |
Overall Length |
4050 mm |
Overall Height |
2550 mm |
|
Overall Width |
1600 mm |
|
Max. discharge height |
2300 mm |
|
Wheel base |
1580 mm |
|
Tread |
1400 mm |
|
Operating Specifications |
Steering System |
Articulated Frame with Hydraulic steering |
Min. Turning Radius |
3900 mm |
|
Transmission |
Manual clutch |
|
Brake System |
Service Brake |
Four Wheel Hydraulic spread-shoed brake |
Parking Brake |
Hand operated |
|
Tire |
8.25-16 |
|
1 Packaging Details: 3 units in one 40 foot container, naked packing
2 Delivery Detail: within 25days after down payment
1)A professional international sales team, which enable us to turn inquiries into final products and export them to numerous countries and regions without barriers;
2) A well managed quality control system to customize on clients requirements. We can design according to customers usage invironment.
3)Unparalleled after sales service
1. How to order?
-After you decide to purchase, we will send you proforma invoice with our bank information, bring this PI to the bank, and ask to make T/T for the deposit. For single set, your machine can be ready within 26 days after we getting the deposit, we will send to the port and deliver to you by sea.
-In case for more handling charges, you can transfer 100% of the payment, we can arrange the products and shipping under your allowance.
-If you still don't understand, please do not hesitate to ask me.
2. Related products?
ZL06F ZL08F ZL10F ZL12F ZL15F ZL16F ZL20F
3. How do we visit you and your factory?
-First of all, welcome you or any appointed agent to vist and inspect our factory.
-You can fly to Shanghai airport, then come from Shanghai railway station to Weifang city. (3 hours)
-You can fly to Qingdao airport, then come from Qingdao railway station to Weifang city. (45 minutes)
-We can pick up you at Qingdao airport or Weifang railway station.
-Please kindly let us know your schedule in details, so that we can arrange everything for you.
5. Why you choose us?
-As manufacturer, our products have excellent quality and competitive price.
-Good after-sales services and 24 months warranty are visible.
-Strictly testing and checking before shipping.
-7 years experience in manufacturing and 7 years exporting experience in Alibaba and Made-In-China.
6. How to contact with me?
-Sales director: Mr Alex Zhu
-Mob: 86 13081451066
-Address: Office add: R 2007 rongguanhuafu B Kuiwen, Weifang, Shangdong, China
Factory add: Shanshui Road,Changle,Weifang,Shangdong,China
