HID 12 inch mini sea sand mud cutter suction dredger dredging boat for sale
u This cutter suction dredger is designed to operate in sheltered inshore waters and under tropical climate conditions.
u Design according to the ZC Standard; build according to the Enterprise Standard.
u It is of all welded steel construction ,bottom plate 10 mm thickness and shell plate 6 mm thickness. 3 hydraulic operated winches in the front of the marine engine deck,2 fixed spud on the aft .2 double ballast tank(fwd and aft) and 2 anchor boom each side.
u The whole dredger is dismountable in road transportable sections, railway and ship transportable.
HID-4016 Cutter Suction Dredger
General Principle
(1). Overall Length 36m
(2). Side Pontoon Size 25m
(3). Main Pontoon Size 16.0m
(4). Breadth 7m
(5). Moulded Depth 2.0m
(6). Mean Draft 1.2m
(7). Dredging Depth 15m
(8). Pumping Distance 1500m
(9). Pump Flow Capacity 2000m³/h
(10).Suction Pipe Dia 450mm Out Diameter
(11) Discharge Pipe Dia 400mm Out Diameter
Main Pontoon
(1). Dimension 16m*3.0m*2.0m
(2). Bottom Plate Thick 12mm CCSB marine plate
(3). Side Wall Thick 8mm CCSB marine plate
(4). Front and Rear 16mm CCSB marine plate
Side Pontoon
(1). Dimension 25m*2.0m*2.0m
(2). Bottom Plate Thick 10mm
(3). Side Wall Thick 6mm
(4). Front and Rear Thick 6mm
1,Engineers available to service machinery overseas.
2,12month warranty for the quality of generator ,gearbox, dredger pump, hydraulic system, spud cylinder.
3,design according to ZC standard ,build according to Enterprise Standard.
4,many design patent
5,digital intelligent operation
6,no blocking pump and hydraulic propeller
7,8 office in different cities,and export to 32 countries
8,the first dredger ,the first factory have ZC ship production certificate and the first submersible pump in the qingzhou dredger industry
9,customized for different geographical condition
10,X-ray exploration , sand blasting and derusting.
Shandong Haohai Dredging Equipment Co. Ltd. is located in the Economic Development Area of Qingzhou City, Shandong Province, a professional and innovative scientific research base established by Qingzhou Yongsheng Dredging Machinery Co. Ltd. The major breakthrough products we have researched and produced are as follows: Dredging Equipment, De-silting Boat, Environmentally Friendly dredger, City Sludge Cleaning Equipment, Sludge Solidification Equipment, Salt Mining Equipment, etc. Many of our products lead in dredging technology globally. With gaining a number of patents, we are the same industry leading enterprise at home, and also a pioneer in leading the dredging industry to upgrade its technology.
Our company covers an area of nearly 50,000 square meters, has fixed assets of 60,000,000 Yuan and 16 R&D personnel. We have established regularly cooperative relationships with Jiangsu Ship Design & Research Institute, Chinese Academy of Agricultural Sciences (CAAS), Nanjing Hydraulic Research Institute, Shanghai Ship Design Institute, and more. We own a variety of professional scientific research equipment and experimental pool for testing the products. Our products have been exported to 33 countries including Russia, Poland, Malaysia, Maldives, Venezuela, India, Indonesia, Nigeria, etc., and they have enjoyed popularity around the world.
We are committed to innovative efforts to meet customer demand, which is as our duty. We have been developing first-class products and are creating a world-famous brand. We sincerely hope to cooperate with customers and merchants to jointly strive for mutual benefit, win-win and common development, and to create a brilliant future together!
