1. Our factory introduction
2. sand pump ship in sea description, dredger manufacturer services your dredging project directly.
The products are of a great variety including 800—20000m3/h large scale dredging and sand mining equipments .
The dredger we produce is self-propelled or non self-propelled,portable cutter suction dredger. The hull uses dismantle and box-like structure, which equipped with horizontal shifting devices, cutter ladder lifting devices, spud devices, deck crane and so on. It can also be equipped with anchoring poles and trolley devices. Generally, it has functions on dredging, conveying and discharging of mud or sand. It can produce certain amount of vacuum by the centrifugal pump.
About Installation
the seller provides two technical engineers who are skilled and experienced in their respective skills who are competent to adequately do the work at hand.
Labour
Before the dismantle dredger to the working site, the buyer shall arrange 6-8workers for installation and learn how to operation.
The buyer shall be responsible for the recruitment, transportation, accommodation, medical care and catering of all labor, local or expatriate, required for the execution of the contract and for all payments in connection therewith.
the seller responsible, at his own cost, for obtaining all necessary permits and or visa from the approciate authorities for the entry of all labour and personnel to be employer on the site.
scope of works.
the work include design, testing like at working site before ex-factory, dismantle, supply, installation, testing at working site, and commissioning of complete silt dredging equipment along with all necessary accessories suitable for the working site. Some of the scope of works inlcude but not limited to :
1. planning and design of dredging system specifically suited for the working site
2. designing and supplying of all necessary accessories/parts such as suction head, suction pipe(flexible sections ), outlet pipe(PE sections or steel pipeline with flexible joints), floaters and anchor system of pipes, outlet valves, pumps and variaty of spares.
3.All associated civil works such as anchoring of equipments when on floatation, docking place in case of non-operation.
nceptual drawings with product images.
5. Installation, testing and commissioning of the equipment including all the required manpower.
6.Arrangement of mobile cranes for handling equipments at site for erection at buyer's side, testing and commissionning at the seller's side.
7. In the process of testing and commissioning, engineers of seller do also provide training of workers how to operation.
8. Supply of fast running spares.
Note
All necessory tools, tackles, plants and machineries required for the installtation, testing and commissioning of dredging equipment shall be in the scope of the buyer.
It is the responsibility of the buyer to store of the material at appropriate locations at their own cost if required. however, storage site shall be provided by the buyer.
3. Product images for your references
4. Specifications for your choosing
| Principal Dimensions and Characteristics | |||
| Year Built: | 2012 | ||
| Length Over All: | 21 m | 69 feet | |
| Beam: | 7.5 m | 25 feet | |
| Height: | 2 m | 7 feet | |
| Weight: | 40 tonnes | ||
| Working Load: | 2,500 cubic meters/hr | 3,270 cubic yards/hr | |
| Digging Depth: | 16 m | 52 feet | |
| From water level to the max. depth: | |||
| Operating System: | Hydraulic and Suction | ||
| With cabin room for operating and controlling | |||
| Discharge Distance: | 1,200 m | 3,937 feet | |
| From working site to the destination where mud is discharged | |||
| Suction Pipe diameter: | 460 mm | 18 inches | |
| Discharge Pipe diameter: | 420 mm | 16 inches | |
| Main Engine | |||
| Make/Model: | Cummins - diesel engine | ||
| Power: | 650 kW | 872 hp | |
| Cutter Head | |||
| Diameter: | 1,500 mm | 59 inches | |
| Oil Cylinder | |||
| Diameter: | 160 mm | 6 inches | |
| Max Oil Consumption: | 0.2 kg/hr | ||
| Generator | |||
| Power: | 15 kW | 20 hp | |
| Emergency Generator | |||
| Make/Model: | Cummins | ||
| Power: | 30 kW | 40 hp | |
| Hydraulic Cutter | |||
| Power: | 100 kW | 134 hp | |
| Hydraulic Winch | |||
| (3) Three Sets - 8 tonnes KN | |||
| Hydraulic Oil Cylinder | |||
| Diameter (2) Two Sets: | 160 mm | 59 inches | |
| Hydraulic Pump | |||
| Make/Model: | Vickers, Nanjing City | ||
| Hydraulic Valve | |||
| Make/Model: | Rexroth | ||
Specifications List One
| Item/model | HCL200 | HLC250 | HLC250A | HLC300 | HLC300A |
| Pump size | 8inch | 10inch | 10inch | 12ich | 12inch |
| Pump flow | 800m3/h | 1100m3/h | 1500m3/h | 2000m3/h | 2500m3/h |
| Capacity | 160CBM/H | 220CBM/H | 300CBM/H | 400CBM/H | 500CBM/H |
| L*B*H | 15.5*7.2*2m | 15.5*7.2*2m | 15.5*7.2*2m | 21*7.5*2m | 21*7.5*2m |
| Dredging depth | 8m | 10m | 10m | 10m | 10m |
| Average draught | 1.3m | 1.3m | 1.3m | 1.4m | 1.4m |
| Discharge distance | 600m | 1000m | 800m | 1200m | 1200m |
| Diameter suction/discharge pipe | 325/300mm | 350/350 | 377/377mm | 426/410 | 460/420mm |
| Diameter of cutter head | Φ1100mm | Φ1100mm | Φ1100mm | Φ1300mm | Φ1300mm |
| Main engine power | 258kw | 300kw | 450kw | 600kw | 650kw |
| Diameter oil cyclinder | 100mm | 100mm | 100mm | 160mm | 160mm |
| Emergency genset | 15kw | 15kw | 15kw | 15kw | 15kw |
Specifications List two
| Item/model | HCL350 | HLC400 | HLC450 | HLC500 | HLC600 |
| Pump size | 14inch | 16inch | 18inch | 20inch | 24inches |
| Working load | 3000m3/h | 3500m3/h | 4000m3/h | 6000m3/h | 8000m3/h |
| Capacity | 600CBM/h | 700CBM/h | 800CBM/h | 1200CBM/h | 1600CBM/h |
| L*B*H | 23.5*7.5*2.4m | 23.5*7.5*2.4m | 23.5*8*2.4m | 26*8.5*2.6m | 29*10*3.0m |
| Dredging depth | 15m | 15m | 15m | 15m | 15m |
| Average draught | 1.6m | 1.6m | 1.6m | 1.7m | 2m |
| Discharge distance | 1500 m | 1500m | 1500 m | 2000m | 2500m |
| Dia.suction/discharge pipe | 550/500mm | 610/550mm | 630/570mm | 680/650mm | 810/780mm |
| Diameter of cutter head | Φ1550mm | Φ1550mm | Φ1700mm | Φ2200mm | Φ2450mm |
| Main engine power | 1000kw | 1050kw | 1200kw | 1580kw | 2400kw |
| Diameter oil cyclinder | 160mm | 160mm | 160mm | 200mm | 250mm |
| Emergency genset power | 24kw | 24kw | 24kw | 30kw | 30kw |
4. Testing center
5.Working site
6.Shipping to the port
7. Cummins engine
8.Working cabin
9. Spares
10. Cutter head
11. customer visits
