Help CenterChina Hydraulic Cutter Suction Sand Dredger Hot Sale in India
Related Products
-
18inch Pond/River /Sea Sand Cutter Suction Dredger With Double PumpUS$ 100,000 - 1,000,000MOQ: 1 Set -
Low Price Hot Sale China Cutter Suction Sand Mining Dredger With Dredging EquipmentUS$ 100,000 - 1,000,000MOQ: 1 Set
-
Non Self Propelled River/Sea/Lake/Port Diesel Cutter Dredger MachineUS$ 100,000 - 1,000,000MOQ: 1 Set
-
China Cheap River Sand Dredge With Cutter Head Dredging MachineUS$ 100,000 - 1,000,000MOQ: 1 Set
-
Heavy Duty River/Sea/Port/Lake/Reservoir Cutter Suction Dredger MachineUS$ 100,000 - 1,000,000MOQ: 1 Set
1. Weifang Jin Meng Dredger Co., Ltd.
|
Weifang Jin Meng Dredger Co.,Ltd. located in Qingzhou, Weifang City, is a manufacturer for hydraulic sand dredger, work boat and gold dredging equipment,which is specialized in dredger researching, designing, production and sales. We have professional R&D department, CAD drawing design center, quality control department and after sales service department. Our company has more than over 500 employees, including 5 professional senior engineers on dredger building and researching, 16 designers on machinery construction, 8 engineers on quality inspecting and controlling as well as 10 after sales service engineers. |
| The company is popular recognized by customers for strong technical strength, high quality hydraulic sand dredgers and good after-sale service. At home the products are sold to dozens of domestic provinces, municipalities and autonomous regions; in abroad the hydraulic sand dredgers are sold to India, Iran, Oman, the United Arab Emirates , Argentina, Colombia, Saudi Arabia, Bangladesh, Egypt, Nigeria, Mongolia, Russia and so on. |
2. Hydraulic Sand Dredger
|
The hydraulic Sand dredger we produce is self-propelled or non self-propelled,portable hydraulic sand dredger. The hull uses dismantle and box-like structure, Its dismantle type can be assembly at working place easily and be transported by road, railway and container accordingly, convenient in installation and working place moving from one to another. The power system can be designed to electric system or diesel engine driving system according to customers’ requirements.Equipment on the hydrasulic sand dredgers are as bellows: traversing device, cutter ladder lifting device, spuds and deck crane. The working process is as following: the cutter head cut the sand and mud underwater to mixture of slurry, then through dredging pump to the pipeline on dredger; at the end the slurry will be discharged by pipeline on land to the required place. Functions of hydraulic sand dredger: dredging river, dredging sand, desilting, reclamation for channels and land, and building roads. Working site of hydraulic sand dredger: sea, port, lake, and river. Soil conditions: relative hard soil, harden sand, sludge, sea sand, river sand, clay, mud, and so on. |
3. Specifications for hydraulic sand dredger
| JMD500 hydraulic sand dredger | |||
|
Dredging Pump |
Dia. Discharge pipe | 500mm | |
| Head | 54m | ||
| Max. Working capacity | 1050m3/h | ||
| Discharge distance | 1500m | ||
| Dredging depth | 15m | ||
|
Diesel Engine |
895KW | Cummins | |
| Hydraulic Auxiliary engine | 298KW | Cummins | |
| Emergency Generator | 30KW | Cummins | |
| Total power | 1223KW | ||
| Oil Consumption | 183L/H | ||
| Hull Dismension | LOA*W*D | 36m×7.9m×2.2m | |
| Hydraulic system | Hydraulic pump | VICKERS America (Joint-venture) | |
| Hydraulic Motor | Italy SAI technology(Joint-venture) | ||
| Valves | REXROTH Germany (Joint-venture) | ||
| Operating system | SIEMENS PLC(Imported from Germany) | ||
| Ladder winch | Tension | 100KN | |
| Swing winch | Tension | 100KN | |
| Cutter Head | Crown-like | Φ1750mm | |
| Power | 170KW | ||
4. Workshops for hydraulic sand dredger
|
A. Hull Welding 1. Steel plates- Rust removal ,Antiseptic treatment. 2. Carbon-dioxide arc welding and Submerged-arc welding. 3. Tightness test and inspection B. Deck machinery installation. C. Main engine and auxiliary engine location installation. D. Hydraulic system installation. 1. The pickling , phosphating treatment of the hydraulic pipes. E. The electrical installation F. The Whole hydraulic sand dredger machine test. |
5. Hydraulic Sand dredger Test before ex-factory
| Each hydraulic sand dredger must be tested well before delivery, before test we will send the invitations letter to the buyers to invite them and check the hydraulic sand dredger performance by themselives. |
6. Hydraulic Sand dredger transportated by trucks on road
| The hydraulic sand dredger is dismantled, box-like structure, and can be transported easily by trucks on road. |
7. Assembly in working sites and engineers are available for overseas service
| After hydraulic sand dredger arrive at customers' working site, two experienced engineers will be sent within one week.With the assist work of 6-8 native workers, our engineers will finish the hydraulic sand dredger assembly work and give some training to the native workers. |
8. Customers' Visit
| Welcome customers' visit to our factory , cars are available to pick up from train station or airport, we cam talk more details of hydraulic sand dredger face to face. |
9. Company culture:
Profession, Innovation, and Integrity
