Multi-Lane Sachet Packaging Machine
US$ 10000 - 1000000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Shipu
Place of Origin:
China
Application:
Food
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
60 days
Related Products
-
Model SPPP-50HW Automatic Powder Packaging Machine (With Weighing Feedback)US$ 10000 - 1000000MOQ: 1 Set -
Spml-240t Multi Lane Bag Packaging UnitUS$ 10000 - 1000000MOQ: 1 Set
-
Biscuit Pillow Packaging MachineUS$ 10000 - 1000000MOQ: 1 Set
-
Model SP-W12-D160 Automatic Filling Machine (1 Line 2fillers)US$ 10000 - 1000000MOQ: 1 Set
-
Model SP-L1W-L Automatic Auger Filling Machine(By Weighing)US$ 10000 - 1000000MOQ: 1 Set
Brand Name
Shipu
Place of Origin
China
Application
Food
Condition
New
Packaging Type
Case
Multi-Lane Sachet Packaging Machine
Scope of application
Suitable for fruit juice drinks, tea bags, oral liquid, milk tea, skin care products, tooth paste, yoghurt, cleaning and washing products, oils, cosmetics, carbonated drinks.
Technical parameters
| Name | Multi lane 4 side sachet packaging machine | Multi lane 3 side sachet packaging machine | |||
| Item & Fill method | 1.Liquid&Paste- pump, 2.Granule- Cup, 3.Powder-Auger | 1.Liquid&Paste- pump, 2.Granule- Cup, 3.Powder-Auger | |||
| Model | SPMP-480 | SPMP-720 | SPMP-960 | SPMP-280 | SPMP-560 |
| Lanes number | 2~6 lane | 3~10 lanes | 4~12 lanes | 2~4 lanes | 4~8 lanes |
| Capacity | Max.40 bags/min/lane | Max.40 bags/min/lane | |||
| Volume Range | 1~ 200ml | 1~ 200ml | 1~ 200ml | 1~ 50ml | 1~ 50ml |
| Accuracy | ±2% | ±2% | ±2% | ±2% | ±2% |
| Bag size | L:45-120MM | L:45-120MM | L:45-120MM | L:45-120MM | L:45-120MM |
| W:35-120MM | W:35-120MM | W:35-120MM | W:25-70MM | W:25-70MM | |
| Sealing type | 4 side sealing | 44 side sealing | 4 side sealing | 3 side sealing | 3 side sealing |
| Film width | Max.480mm | Max.720mm | Max.960mm | Max.280mm | Max.560mm |
| Film thickness | Laminated film thickness:0.05--0.12mm | Laminated film thickness:0.05--0.12mm | |||
| Cutting type | 1.Flat Cutting; 2.Zigzag cutting; 3.Continuous cutting; 4.Customized special shape cutting | ||||
| Control system | PLC+Servo+Touch screen | PLC+Servo+Touch screen | PLC+Servo+Touch screen | PLC+Servo+Touch screen | PLC+Servo+Touch screen |
| Air consumption | 0.8 MPA 0.6M3/MIN | 0.8 MPA 0.6M3/MIN | 0.8 MPA 0.6M3/MIN | 0.8 MPA 0.6M3/MIN | 0.8 MPA 0.6M3/MIN |
| Power Supply | 3.5KW,220V 50Hz/60Hz | 5KW,220V 50Hz/60Hz | 6.5KW,220V 50Hz/60Hz | 4.5KW,220V 50Hz/60Hz | 6.5KW,220V 50Hz/60Hz |
| Dimension | 1385*918*H2005mm | 1685*1300*2005mm | 1415*1686*2220mm | 1385*918*2005mm | 1685*1300*2005mm |
| Weight | 350KG | 450KG | 550KG | 350KG | 450KG |
| Name | Multi lane back side sachet packaging machine | |
| Item & Fill method | 1.Liquid &Paste- pump, 2.Granule- Cup, 3.Powder-Auger | |
| Model | SPMP-280B | SPMP-560B |
| Lanes number | 2~6 lanes | 4~12 lanes |
| Capacity | Max.35 bags/min/lane | Max.35 bags/min/lane |
| Volume Range | 1~ 50ml | 1~ 50ml |
| Accuracy | ±2% | ±2% |
| Bag size | L:50-180MM | L:50-180MM |
| W:17-60MM | W:17-60MM | |
| Sealing type | Back side sealing | Back side sealing |
| Film width | Max.280mm | Max.560mm |
| Film thickness | Laminated film thickness:0.05--0.12mm | Laminated film thickness:0.05--0.12mm |
| Cutting type | 1.Flat Cutting; 2.Zigzag cutting; 3.Continuous cutting; 4.Customized special shape cutting | |
| Control system | PLC+Servo+Touch screen | PLC+Servo+Touch screen |
| Air consumption | 0.8 MPA 0.6M3/MIN | 0.8 MPA 0.6M3/MIN |
| Power Supply | 4.5KW,220V 50Hz/60Hz | 6.5KW,220V 50Hz/60Hz |
| Dimension | 1385*918*2005mm | 1685*1300*2005mm |
| Weight | 350KG | 450KG |
