FIGURE 100 HAMMER UNIONS
Figure 100 hammer union is black nuts yellow parts. These hammer union with precision machined metal-to-metal sealing surfaces. Recommended for low-pressure manifold line connections and application in air ,water, oil and gas. Service the working pressure is not more than 1000psi. And we can be produced according to customer requirements .
Feature:
u Pressure-tight make-up with hammer
u Economical low-pressure union
u Manifold and line connections
The detail of fig100 hammer union:
u Working Pressure:1000PSI
u Size : 2’’-8’’
u Union color : black nuts yellow part
u Material : SF
Specification :
Nominal pipe size |
Total length |
Nut radius |
Material |
Weight |
|||||
in |
mm |
in |
mm |
in |
mm |
nut |
subs |
lbs |
kgs |
2 |
50.8 |
35/8 |
92.1 |
215/16 |
74.6 |
SC/SF |
SF |
5.25 |
2.4 |
2-1/2 |
63.8 |
41/4 |
108.0 |
35/8 |
92.1 |
SC/SF |
SF |
8.0 |
3.6 |
3 |
76.2 |
415/16 |
125.4 |
41/16 |
103.2 |
SC/SF |
SF |
14.0 |
6.4 |
4 |
101.6 |
515/16 |
150.8 |
425/32 |
121.4 |
SC/SF |
SF |
23.0 |
10.4 |
6 |
152.4 |
65, /8 |
168.3 |
67/16 |
163.5 |
SC/SF |
SF |
44.5 |
20.2 |
8 |
203.2 |
71/4 |
184.2 |
711/16 |
195.3 |
SC/SF |
SF |
61.0 |
27.7 |
Hebei Huayu Special Rubber Co., Ltd. We have many years experience to produce the unions also have advanced equipment and skilled workers to control the product quality and we have been focusing on research and development the best products in recent years . With our best service attitude and the good products ,we have established long term cooperation relationship with many large companies and we have exported our union products to many countries.
We are the leading manufacturer of complete union products, such as fig 100 hammer union , fig 200 hammer union ,fig 206 hammer union ,fig 207hammer union , fig 400 hammer union , fig 602 hammer union ,fig 1002 hammer union , fig 1003 hammer union , fig 1502 hammer union air grip union, mud tank union , stainless steel hammer union , self-sealing union ,blind hammer union , test cap hammer union.They are used pipe line and high pressure equipment connection ,they have different cold working pressure and structure but our union are easy installation and uninstall .
