Structure: The hose consists of an inner tube, reinforcement layer, middle layer and rubber cover.
Feature: The hose body length decreased, the diameter increase and on the expansion state after hose enduring internal upright pressure. Under this conditions, the hose accomplishes the hole sealing function.
Application:
A. Apply to coal mine and clear dust.
B. Apply to engineering construction and leak prevention construction underground.
C. Apply to tunnel exploitation and pour cast underground and underwater.
Inside Diameter |
Outside Diameter |
Expansion Range |
Hole Radius |
Working Pressure |
Burst Pressure |
mm |
mm |
mm |
mm |
MPa |
MPa |
22±0.5 |
39±2 |
+8-4 |
50 |
6 |
29.4 |
22±0.5 |
39±2 |
+8-2 |
50 |
6 |
29.4 |
32±0.5 |
48±2 |
+8-4 |
56 |
6 |
29.4 |
32±0.5 |
48±2 |
+8-2 |
56 |
6 |
29.4 |
38±0.8 |
54±2 |
+8-4 |
65 |
4 |
16 |
38±0.8 |
54±2 |
+8-3 |
65 |
4 |
16 |
45±0.8 |
60±2 |
+8-4 |
75 |
4 |
16 |
45±0.8 |
60±2 |
+8-3 |
75 |
4 |
16 |
51±1 |
69±2 |
+8-4 |
91 |
4 |
16 |
51±1 |
69±2 |
+8-3 |
91 |
4 |
16 |
64±1 |
80±2 |
+8-4 |
110 |
4 |
16 |
64±1 |
80±2 |
+8-3 |
110 |
4 |
16 |
76±1 |
94±2 |
+8-4 |
130 |
2 |
12 |
76±1 |
94±2 |
+8-3 |
130 |
2 |
12 |
We can produce the packer as your special requirement.
We also provide the inflatable packer hose.
