Structure: The hose consists of an inner tube, reinforcement layer, middle layer and rubber cover.
Feature: The hose body length decreased, the diameter increase and on the expansion state after hose enduring internal upright pressure. Under this conditions, the hose accomplishes the hole sealing function.
Application:
A. Apply to coal mine and clear dust.
B. Apply to engineering construction and leak prevention construction underground.
C. Apply to tunnel exploitation and pour cast underground and underwater.
Inside Diameter | Outside Diameter | Expansion Range | Hole Radius | Working Pressure | Burst Pressure |
mm | mm | mm | mm | MPa | MPa |
22±0.5 | 39±2 | +8-4 | 50 | 6 | 29.4 |
22±0.5 | 39±2 | +8-2 | 50 | 6 | 29.4 |
32±0.5 | 48±2 | +8-4 | 56 | 6 | 29.4 |
32±0.5 | 48±2 | +8-2 | 56 | 6 | 29.4 |
38±0.8 | 54±2 | +8-4 | 65 | 4 | 16 |
38±0.8 | 54±2 | +8-3 | 65 | 4 | 16 |
45±0.8 | 60±2 | +8-4 | 75 | 4 | 16 |
45±0.8 | 60±2 | +8-3 | 75 | 4 | 16 |
51±1 | 69±2 | +8-4 | 91 | 4 | 16 |
51±1 | 69±2 | +8-3 | 91 | 4 | 16 |
64±1 | 80±2 | +8-4 | 110 | 4 | 16 |
64±1 | 80±2 | +8-3 | 110 | 4 | 16 |
76±1 | 94±2 | +8-4 | 130 | 2 | 12 |
76±1 | 94±2 | +8-3 | 130 | 2 | 12 |
We can produce the packer as your special requirement.
We also provide the inflatable packer hose.
