hot sale factory good quality belt conveyor in very competitive price/good quality rubber conveyor belt
high quality EP conveyor belt
Usage:
Suitable for factories, ports, docks, long distance, high strength, large volume of use.
Varieties:
According to cover the performance can be divided into: ordinary type, smoldering, heat-resistant, wear-resistant, and resistant to. Cold type, acid type, oil type varieties.
Features:
Allow the use of high strength, high safely coefficient; elongation minima, tension travel a short distance; minimal tension elongation, travel a short distance; Steel wire rope and rubber combined with a solid, excellent dynamic performance; the belt body is soft, into a good grove, linear operation is good; excellent shock resistance; joint reliability, long service life.
Technical performance:
The performance in line with the GB/T5753-2008 standard; cover tape performance if user special requirements please contact us; impact resistance to tearing type can improve the impact resistance performance of 1-2 times, the tear resistance increase 0.5-1 times; cold-resistant lowest working temperature.
Techncial index list of conveyor belt:
Belt type |
Fabric type |
Single Fabric strength (N/mm) |
Rubber cover thickness (mm) |
Total thickness (mm) |
Ply |
Belt width (mm) |
Belt length (m)/roll |
|
Top rubber |
Bottom rubber |
|||||||
Cotton Canvas (CC) conveyor belt |
CC-56 |
56 |
3.0-6.0 |
1.5-6.0 |
3-30 |
3-12 |
300-2800 |
200m |
Nylon (NN) conveyor belt |
NN100 |
100 |
||||||
NN150 |
150 |
|||||||
NN200 |
200 |
|||||||
NN250 |
250 |
|||||||
NN300 |
300 |
|||||||
NN400 |
400 |
|||||||
NN500 |
500 |
|||||||
NN600 |
600 |
|||||||
Polyester (EP) conveyor belt |
EP100 |
100 |
||||||
EP150 |
150 |
|||||||
EP200 |
200 |
|||||||
EP250 |
250 |
|||||||
EP300 |
300 |
|||||||
EP350 |
350 |
|||||||
EP400 |
400 |
|||||||
EP500 |
500 |
|||||||
EP600 |
600 |
|||||||
Rubber performance levels of conveyor belt:
Level Code |
Tensile strength Mpa≥ |
Elongation at break % ≥ |
Wear mm3 ≤ |
D |
18 |
400 |
90 |
H |
25 |
450 |
120 |
L |
20 |
400 |
150 |
P |
14 |
350 |
200 |
Note:D-strong wear working conditions;H-strong draw crack working condition;L-general working conditions;P-oil resistant,heat resistant,acid and alkali resistant,cold resistant and general flame resistant conveyor belt. | |||
Hebei Lianxing Plastic Co., Ltd. , is a manufacturer specializing in the production of high-pressure hose and assemblies for, with a registered capital of 15 million yuan, covers an area of 40000 square meters, construction area of 25000 square meters, all kinds of technical personnel 168 people, theproduction of products with good flexure, fatigue resistance, withstand high pressure, pulse strength, at a temperature of - 40 DEG C to 100 DEG C to delivery with a certain pressure of hydraulic oil, fuel oil, lubricating oil, emulsion, air and water, application ,engineering machinery, iron and steel manufacturing, coal stent, oil drilling, shipbuilding, and other industries.
1: We accepet OEM servive
2: We have a year of quality assurance.
3: We have our own factory,will provide best price and quality.
