Mining Ball Mill grinder machine
- 20 Set / Sets per Month
- shanghai
- T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
Product Details
Brand Name: | ZK MACHINE | Place of Origin: | China | Type: | Ball Mill |
Certification: | ISO,CE | After-sales Service Provided: | Engineers available to service machinery overseas | Warranty: | 1year |
Condition: | New | Motor Type: | AC Motor |
Product Description
Ball Mill Application:
The ball mill is a key equipment to grind the crushed materials, and the ball mill is widely used in powder-making production line including cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, glass ceramics, etc, and the ball mill can grind various ores and other materials with dry type and wet type. There are two kinds of ball mill, grate type and overfall type due to different ways of discharging material.
Ball Mill Working Principle:
Energy-Saving Ball Mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.
Technical data of Ball mill :
Model | Drum rotary Speed (r/min) | ball Weight (t) | Feeding Size (mm) | Output (t/h) | Power (kw) | Weight (t) |
900*3000 | 37.4 | 2.7 | ≤20 | 0.8 | Y225M-6-22 | 5.8 |
1200*2400 | 30 | 4.80 | ≤20 | 1.4-2 | JQ094-8-37 | 12.5 |
1200*4500 | 30 | 6 | ≤25 | 1.4-3 | Y280M-8-55 | 13.8 |
1500*1500 | 28.8 | 5 | ≤25 | 1.4-3.5 | Y315S-8-45 | 14 |
1500*3000 | 28.8 | 8 | ≤25 | 2.5-4 | JR125-8-75 | 17 |
1500*5700 | 28.8 | 12 | ≤25 | 4-6 | JR127-8-130 | 25 |
1830*4500 | 25.5 | 18.5 | ≤25 | 7.3-17.2 | JR138-8-180 | 34.5 |
1830*6400 | 24.23 | 20 | ≤25 | 7.5-19.2 | JR138-8-210 | 36.55 |
1830*7000 | 24.5 | 21 | ≤25 | 7.5-20 | JR138-8-245 | 38 |
2100*3600 | 21.9 | 19 | ≤25 | 6-17 | JR138-8-245 | 43 |
2200*6500 | 21.9 | 31 | ≤25 | 12-16 | JR138-8-280 | 46 |
2200*7500 | 20.4 | 39.5 | ≤25 | 15.6-18.1 | JRQ1410-8-280 | 68 |
2400*9000 | 20.4 | 60 | ≤25 | 18-24 | TR1512-8-630 | 104 |
