In the continuous type Ball Mill, the material is being fed from the one end through its hollow shaft, while the crushed material comes out from the hollow shaft, at the other end. Usually continuous Mills are used when the production rate is required to be high.
Specially designed for ：Cement, Iron Ore, Copper Ore, Alumina, Cement, Calcium Carbonate, Bauxite, Calcium Carbide, Calcium Oxide, Ceramic, Refractory, Slurry, Coconut shell, Carbon industries etc.
Structure
Ball mill main parts: Feeding part, discharging part, rotary part, driving part (reducer, small driving gear, electric motor and electric control) and other major parts.
OUR ADVANTAGE
1. Energy saving and Long working life: Traditional sliding bearings are replaced by double row roller bearings in small and medium size ball mill to reduce energy consuming, new endurable wearing parts to increase service life of vulnerable parts.
2. Big crushing ratio and High ore particle fineness: The intrinsic grille pattern forcing evacuation is instead by over fall pattern controlling one. This can improve the milling of the granule and the quantity dealt.
3. Simple structure and convenient maintenance: Ball Mill changes the complicated grinding mill structure. We design the body and chassis integration which makes it easy to place the machine on the ground. Three meters of the ball machine above is especially configured with jack-up devices for easy maintenance.
4. Good corrosion resistance and Runs steadily and efficiently: The rotary rack wheel uses casting gear hobbing and inside the cylinder there is wear-resisting lining board which has fine abrasion performance. This ball mill has stable operation and reliable performance.
5. Easy installation Adjustment, and operation and High technology: Low speed driving unit with lifting device; Large ball mills adopt pitot pressure or hydrostatic bearings.
Specifications
model |
cylinder rev(r/min) |
grind media weight (t) |
feeding size(mm) |
output size(mm) |
output (t/h) |
motor |
|
type |
power |
||||||
MQG900X1800 |
38 |
1.8 |
≦25 |
0.074-.06 |
0.8-1 |
Y255M-8 |
22 |
MQG900X3000 |
37.4 |
2.7 |
≦25 |
0.074-0.3 |
0.8 |
Y225M-6 |
30 |
MQG1200x2400 |
32 |
4.8 |
≦25 |
0.074-.06 |
1.5-2 |
Y280M-8 |
45 |
MQG1200X4500 |
30 |
5.2 |
≦25 |
0.074-.06 |
1.5 |
Y280M-6 |
55 |
MQG1500x4500 |
28.8 |
10 |
≦25 |
0.074-0.4 |
3-4 |
JR126-8 |
110 |
MQG1500x5700 |
28.8 |
12 |
≦25 |
0.074-0.4 |
3-5 |
JR127-8 |
130 |
MQG1500x6400 |
28.8 |
13 |
≦25 |
0.074-0.4 |
3-5 |
JR127-8 |
130 |
MQG1830x5400 |
24.5 |
15 |
≦25 |
0.074-0.4 |
5-7 |
JR137-8 |
210 |
MQG18306400 |
24.5 |
19 |
≦25 |
0.074-0.4 |
5-7 |
JR137-8 |
210 |
MQG1830x7000 |
24.5 |
20 |
≦25 |
0.074-0.4 |
6-8 |
JR138-8 |
245 |
MQG2200x7000 |
21.6 |
30 |
≦25 |
0.074-0.8 |
8-10 |
JR158-8 |
380 |
MQG2200x9000 |
21.4 |
34 |
≦25 |
0.074-0.8 |
8-10 |
JR1510-8 |
475 |
MQG2400x7000 |
20.4 |
36 |
≦25 |
0.074-0.8 |
10-14 |
JR1510-8 |
475 |
MQG2400x8000 |
20.4 |
42 |
≦25 |
0.074-0.8 |
10-14 |
YR630-8 |
560 |
MQG2600x8000 |
19.6 |
52 |
≦25 |
0.074-0.8 |
16-20 |
JR1512-8 |
630 |
MQG3000x9000 |
18.3 |
78 |
≦25 |
0.074-0.8 |
20-25 |
YR1000-8/1180 |
1000 |
