Product Details
Application：
For the professional test of peeling force and bond strength Of various kinds of flexible laminated plastics or equivalents.
Features：
1. Professional in peeling force and bond strength test.
2. Designed based on various standards.
3. 90 peel, 180 peel, T-type peel etc.
4. Touch screen operation, real color TFT LCD display.
5. Patent technology.
6. High accuracy load cell built-in.
7. Test speed can be preset freely on touch screen.
8. Micro-printer prints mini-report.
9. Different load cell range can be selectable.
10. Various professional grips can be optional.
11. Overload protection.
12. RS232 communication port.
13. Professional computer software support.(optional)
Technical Indexes：
| Load cell range | 5N, 10N, 30, 50N, 200N |
| Accuracy | 0.3%FSMAX |
| Test speed | 1mm/min - 500mm/min |
| Speed accuracy | 1mm/min |
| Peeling distance | 470mm |
| Sample width | 10mm, 15mm, 20mm, 25.4mm, 50mm (optional) |
| Power supply | AC 220V 50Hz |
| Consumption | 30W |
| Dimension | 750mm (L) X 340mm (W) X 120mm (H) |
| Net weight | 43kg |
