double head upvc welding machine
The machine is used for welding and the combination. With PLC and pneumatic driving systems, it has the features of high reliability, large processing range and easy operation. The two heads can work individually, simultaneously and combinatively.
Features:
1.PLC controls the welding action / program, high reliability
2.Machine heads can work separately or jointly
3.Free angle welding of right machine head
4.Parameters can be set to meet various profiles' processing requirements
5.High welding precision
6.Imported PLC and other main electric components.
7.Good welding corner 1.PLC controls the welding action / program, high reliability
| Input voltage | 380V/50Hz |
| Input power | 3.5Kw |
| Air pressure | 0.4-0.6Mpa |
| Air consumption | 200L/min |
| Welding height | 20-120mm |
| Welding width | 100mm |
| Welding length | 400-3500mm |
| Overall dimension | 4400*1100*1650mm |
| Weight | 1200Kgs |
Note:
Most Electrics Part are CE or UL Standard
Payment: Telex Transfer (T/T), 30% be paid after confirming the order and the rest 70% is effected while delivering the goods.
Package: Each PC in wooden cases.
Port of Loading: Qingdao, China
Delivery Time: During 20 working days after we receive your first payment.
Trade Mark:SUNNY
Contact Information:
Ceci Liu
Mobile:0086-15098968538
Whatsapp:+8615098968538
Skype:missliu106
5.1)Guarantee the complete machine for one year, except the consumable parts.
2) 24hour technical support by email or calling.
3) User-friendly english manual for machine using and maintaining.
GOOD Quality, GOOD SERVICE IS AVAILABLE, ANY INQUIRY FROM YOU WILL BE APPRECIATED.
