Battery Operate Glass Sheet Vaccum Lifter

Battery Operate Glass Sheet Vaccum Lifter photo-1
Battery Operate Glass Sheet Vaccum Lifter photo-2
Battery Operate Glass Sheet Vaccum Lifter photo-3
Battery Operate Glass Sheet Vaccum Lifter photo-4
Battery Operate Glass Sheet Vaccum Lifter photo-5
Battery Operate Glass Sheet Vaccum Lifter photo-6
US$ 1,900 - 2,300 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
SUNNY
Place of Origin:
Shandong, China
Model Number:
FVL-G800-8
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Brand Name SUNNY
Place of Origin Shandong, China
Model Number FVL-G800-8
After-sales Service Provided Engineers available to service machinery overseas
Warranty 12 month
Dimension(L*W*H) 1200*1200*350mm
Certification CE ISO
Condition New
Power(W) 0.16KW



Product Description





battery operate glass sheet vaccum lifter



The glass lifter can be combined and operated with many different carrier facilities,such ascrane,excavatos, wheel loaders, fork lifts.

Load Movement:

Manual rotation, 360° edgewise, with locking at each quarter point
Manual tilt, 90° between upright and flat, with automatic latching in upright position



FVL-G800-8 Electric glass sucker lifter

Type

FVL-G400-4



Lift capacity

800Kg



Diam. of Suction plate

300mm

Amount

8



Vacuum pump voltage

12V, DC



Vacuum pump capacity

0.16Kw



Work piece size

(3600)L* (3600)W *(---)H mm



Lifter size

(1100)L×(1100)W×(300)H mm



Control mode



Manual Valve



Sound level

<50dB



Rated safety coefficient

8



Weight

120kg



Others

No



battery operate glass sheet vaccum lifter

battery operate glass sheet vaccum lifter

We recommend FVL-G800-8

vacuum lift with rated capacity 400kg for vertical handling. Therere 8 suction cups, each diameter is 300mm. A 0.16Kw America GAST pump is used. Under vacuum pressure 60%(abs. 0.4bar), the suction cups could provide 800kg lift for vertical handling. The safety factor is no less than 4. The main beam is 860mm and cross beam is 860mm.



  Parts List:





 Item



Name



Type



Supplier



Unit



Quantity

1

Suction plate

HFG300

Aerolift production from Germany

Set

8

2

 Oil free vacuum

pump

VT2.2

GAST production from America

 Pcs

1

3

Vacuum filter

F- 1 1/2

Aerolift production from Germany

 Pcs

1

4

Vacuum pressure

switch

Huba625

Beck production from Germany

 Pcs

1

5

Vacuum pressure

meter

VM-63

Acutex production from American

Pcs

1

6

Lifting eye &

operator handle

 integrated control unit











 Made by Freddie

 Pcs

1

7



Main beam

860mm

 Pcs

1

8

Accumulator

 integrated

 Pcs

1

9

Alarm unit



WU type

 Pcs

1

10

 Electric control box



specialized unit

 Pcs

1
