Two Component Sealant Extruder /Insulating Glass Silicone Sealant Machine
US$ 6,000 - 45,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
CNSUNNY
Place of Origin:
Shandong, China
Model Number:
ST02/03/04
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Butyl Coating Machine/Hot Melt Extruder Coating Machine for Insulating Glass Production LineUS$ 2,600 - 4,600MOQ: 1 Set -
Hot Roller Press MachineUS$ 1 - 4,000MOQ: 1 Set
-
Rubber Strip Assembly TableUS$ 1 - 1,400MOQ: 1 Set
-
Two Component Glue Coating MachineUS$ 1 - 5,800MOQ: 1 Set
-
Silicone Sealant Gluing MachineUS$ 1 - 5,800MOQ: 1 Set
Brand Name
CNSUNNY
Place of Origin
Shandong, China
Model Number
ST02/03/04
Certification
SGS CE
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
12 month
Weight
500 Kg
Dimension(L*W*H)
1200X1200X2200mm
Condition
New
ST03 Korean Pump Silicone Extruder- Two Component Sealant Extruder Machine
Automatic Insulating Glass Sealing Robot YGM2500
Functions and Features:
1.It is composed of raw material pump,solidification pharmaceutical pump,proportional pump, sealant-mixture system,hydraulic pressure system,electric system and so on.
2.Raw material pump,solidification pharmaceutical pump and proportional pump adopt the special high-pressure filling pump and the materials can be supported equivalently in two-way.The raw material pump is compelled by the hydraulic pressure sysem while the solidification pharmaceutical pump is compelled by the pheumatic motor.
3.There are high-pressure valves in the underpart entrance of solidification
pharmaceutitcal filter and material-feeding place of the mixing device and one-way valve is set in the mixing device so as to prevent two-components from fleeing each other.
4.Rising and falling system is controlled by hand valve and the proportion of the two-components can be changed by adjusting the slipper in the swinging pole.Tighening the nut once the demanding scale is reached.
4.Rising and falling system is controlled by hand valve and the proportion of the two-components can be changed by adjusting the slipper in the swinging pole.Tighening the nut once the demanding scale is reached.
Technical Parameter:
Ration : 6:1-14:1
Raw material barrel: 55Gallon(200L)
Solidification pharmaceutical barrel: 5Gallon(20L)
Max.air-consumption volume: 0.5m3/min
Max.squeeze pressure: 20Mpa
Air source presure: 0.5-0.8Mpa
Outside Dimension: 1200*1200*2200mm
Weight: 280kg
