roll forming machine for roof panel
Machine description:
What is the product application for the roll forming machine for roof panel?
The finished product of roll forming machine for roof panel is widely used in the construction of various industrial plants, villages, warehouses, supermarkets, hotels, exhibition, family construction, shopping malls shutter doors and etc. It has the advantage of beautiful, classical appearance and grace taste.
What is the advantage of roll forming machine for roof panel?
1.The system is easy to operate and use. PLC: Delta(Can customize as customer require)
2.the surface of the final product is very smooth and beautiful without any scratch on the surface.
What is the specification of roll forming machine for roof panel?
| Item | Specification |
| Name | roll forming machine for roof panel |
| material | color steel,GI,PPGI |
| Processing thickness | 0.3-0.8mm |
| Diameter of shaft | Φ80mm |
| Electric tension | as the customer's requirements |
| Roller | 45# steel chrome plating chromium |
| Processing precision | within 1mm |
| Transmission | by chain link(1inch) |
| Hydraulic cutting | controlled by PLC |
| PLC | DELTA(TAIWAN) |
| Material of blades | Cr12 quenched |
| Switch | CHNT |
| Roller station | to the finnal design |
What's the Main components of roll forming machine for roof panel?
Above main components of our roll forming machine for roof panel , and we adopt high quality raw material to guarantee our machine long-life working. All electrical parts are famous brand.
Decoiler |
1set |
Feeding & guiding device |
1set |
Main roll forming machine |
1set |
Hydraulic pressing system |
1set |
Hydraulic cutting system |
1set |
Controlling system |
1set |
Run out table |
1set |
What is the intoducation of the roll forming machine for roof panel?
1.This roll forming machine for roof panel is made up of roll forming machine,molding press,cutting machine,PLC computer control and hydraulic system.
2.The metal roofing machines is stable,no noise,no shake.
What is the feature of the roll forming machine for roof panel?
1.Our roll forming machine for roof panel can uses galvanized steel sheet, colored armor plate or galuminum plate as the material plate.
2. Controlling by computer, PLC display, operation is easy, running is steady and reliable,endurable,maintenance-free.
Related machinery
1.Different types roof profile drawing forming machine ;
2.Curve roof roll forming machine ; 3.Ridge cap roll forming machine ;
4.Floor deck roll forming machine ; 5.Rain gutter roll forming machine ;
6.Down pipe roll forming machine ; 7.Highway guardrail roll forming machine ;
8.Roller shutter door forming machine ; 9.Door frame roll forming machine ;
10.CZU purlin roll forming machine ; 11.Light keel roll forming machine ;
12.Slitting machine (lines); 13.Shearing/bending machine ;
14.Decoiler(Hydraulic decoiler ,electric decoiler and manual decoils) and so on .
