| Rated voltage | d.c 6v |
| Coil resistance | 12Ω±0.5Ω(20ºC temperature) |
| Open and close way | DCimpulse |
| Impulse width | 10ms-30ms |
| Working pressure | 0.05Mpa~0.8Mpa |
| Medium temperature | 0.1~60 centigrade (set according to user's requirement) |
| Reacting time | open<0.15s close<0.5s |
| Electric strength | between conductor and nonconductor |
| Flow capability | 0.05Mpa>5L/min 0.3Mpa>20L/min 0.8Mpa>28L/min |
| Working life | more than 500.000 cycles |
| Insulation capability | over 100M between conductor and nonconductor |
Note:
The water will only flow when hands are put within range of the sensor, as soon as the hands are removed the flow will stop. This contributes to considerable water savings
After installation the faucet is in touch free operation, this reduces the risk of transfer of bacteria
SCM control provides a limited water flow of maximum one minute, even when fixed objects are still within range of the sensor
Can also be operated with battery backup (applies to controller #1 only
8pcs/ctn
Inner box size: 29.5x23.5x14.5cm
Carton size: 49.5x45.5x29.5cm
Carton weight: N.W.:12.5kgs G.W.:13.1kgs
Four Core Technologies Of Intelligent Sanitary Ware
Q: Are you one factory or one trading company?
A:Factory
Q:How about the area of your factory?
A: over 5,000 square meters
Q:How many skilled workers do you have ?
A:80- 100
Q:What about your advantage?
A:15-year experience in devotion to intelligent sanitary wares only Strong R&D team, self-designed and self-developed 4 different kinds of core components Quality control exactly and strictly conforms to ISO9001 standard
Q: What kind of certificates to you have ?
A: ISO9001:2000, CE, ROHS, Letter of Patent.
Q: How about your delivery time?
A: In stock: 7-10 days after down payment; Out of stock: Normally 30-45 days
Q: Do you accept OEM/ODM?
A: Yes
