Home > Products > VSAT > Ditel V61 63cm Ku band 3-axis marine VSAT antenna digital satellite receiver internet service for ship
Ditel V61 63cm Ku band 3-axis marine VSAT antenna digital satellite receiver internet service for ship
USD $13000 - $23000
/ Set
1 Set(Min.Order)
- Ningbo, Shanghai
- T/T L/C
- 30 days
You May Like
-
Ditel S45 ku band 45cm mobile auto tracking satellites marine satellite tv antenna for boat
-
Ditel S61 63cm 3-axis ku band outdoor digital marine satellite tv antenna dish antenna
-
Ditel S60 60cm Ku-band ship marine satellite antenna for watching TV
-
Ditel V91 Ku band 90cm 3-axis mobile satellite VSAT communication antenna for boat
-
Ditel S45 ku band 45cm mobile auto tracking satellites marine satellite tv antenna for boat
Product Details
| Brand Name | DITEL | Place of Origin | China | |
| Model Number | Ditel V61 |
Product Description
Ditel V61 63cm KU Band 3-axis marine VSAT antenna for ship
Ditel V61
Featuring a compact size and lightweight design, the Ditel V61 is a 60cm Ku-band maritime VSAT antenna system ideal for smaller vessels with space constraints. With its 3-axis stabilized platform and 5 patent technology, the V61 offers superior tracking performance to users.The 5 patents make the ditel V61 performs super high tracking effiency with 60cm dish while other antennas need 90cm dish at least. 3-axis is preferred in the vicinity of the equator.
Features
| 1. SkyFocusTM super high gain antenna Ring focus antenna providing extra high communication performance. |
2. WatchmanTM double inertial guidance project patent |
| 3. Tri-DoorTM smart failure testing Checking peripheral equipment automatically,preventing system malfunction |
| 4. SingfingerTM one-key operation system Interactive action of state control and parameter input with single button |
| 5. LightenLifeTM Built-in WIFI interface,remote processing system on mobile terminal is available |
| 6. 3-axis stabilized , 4-axis tracking |
Parameters
| Physical parameter | Communication parameter | ||
| Radome Dimension(WxH) | 75*83.8cm (29.78*33 inch) | TX Frequency | 13.75~14.75GHz |
| Weight | 45 kg(99.10 lbs) | TX Gain | 37.6dBi (14.25Ghz) |
| Reflector Diameter | 63 cm (24.8 inch ) | RX Frequency | 10.75~12.75GHz Ku-band |
| Radom Material/Color | ASA / White | RX Gain | 36.4dBi (12.5Ghz) |
| Waterproof level | IP56 | G/T | 14.2dB/K(clear sky,30° Elevation ) |
| Environmental humidity | 0~95% | Power input | AC 100V~240V /DC 24V |
| Operating Temp. Range | -20~70℃ | Power output | DC 24V |
| Tracking paramenter | Statick Power | 50 W W/O BUC | |
| Platform | 3-axis stabilized , 4-axis tracking | Dynamic Pwer | 60 W W/O BUC |
| Tracking mode | bulit-in inertial guidance | BUC Power | 2W/3W / 4W / 6W / 8W(optional) |
| Location mode | BD/GPS location system | Min.EIRP | 46dBW |
| Motor Brake System | Azimuth, roll, pitch | Polarization | linear polarization |
| AZ Range / Tracking rate | Unlimited/ ±30°@5S | side lobe envelope | ITU-RS.456-6 standard |
| EL Range/Tracking rate | -10° ~ 110°/ ±30°@5S | cross polarization isolation | >33DB |
| Roll Range/ Tracking rate | ±35° / ±30°@5S | Antenna type | Ring focus |
| LNB skew Range/ Tracking rate | ±167.5° / ±30°@5S | LNB | KU band L.O.(9.75/10.6/11.3 GHz customizable) |
| Initial lock | ≤60S | ||
| Re-lock after break lock | break lock ≤ 30S: <15S 30S | ||
Connection
Application
Contact Us
