CNC-XJ-200/15 CNC copper aluminum Busbar chamfering machine
CNC busbar chamfering machine CNC-XJ-200/15 makes a good combination of automatic positioning , automatic clamping and automatic Chamfering. This is a high automatic Busbar chamfering equipment with high precision positioning , high convenient and high performance .
This machine is widely used in the electrical switchgear , transformers ,Power transmission and industries copper , aluminum busbar chamfering or milling , avoiding the discharging of rectangular copper / aluminum .
Main Features:
1. Made in China Automatic CNC Type Bus bar chamfering Machinery Using automatic technology, making the pressure head on the point.
2.With a supercharger, it can make the workpiece more stable and better processing surface.
3.Adopt international standards BT4o knives, change tools easy with good rigid high accuracy.
4.High accurate ball screw transmission and straight guide to guarantee high precision& efficiency.
5.The adopted component is world-famous,with long service and good quality.
6.Easy Operating software, easy to learn and use.
Item |
Unit |
Parameter |
|
Cutting Section |
Rotational Spindle speed |
R/min |
Min:88 Max:1256 （adjustable） |
Motor Power |
kW |
7.5 |
|
Handle Model |
BT40 |
||
Feeding Section |
Stroke of X-axis |
mm |
250 |
Stroke of Y-axis |
mm |
350 |
|
Servo power |
kW |
2×1.5 |
|
Feeding Speed |
mm/min |
1200 |
|
Knife Parameter(Diameter) |
mm |
100 |
|
Min Allowable Length of Plate |
mm |
280 |
|
Max Allowable Plate(WidthxThickness) |
mm |
200×15 |
|
Min Allowable Plate(WidthxThickness) |
mm |
30×3 |
|
Air Pressure |
Mpa |
0.5～0.9 |
|
Oil pressure |
KN |
300 |
|
Voltage Total Power |
Kw |
12 |
|
Outside Dimension |
mm |
2550×2050 |
|
Total Weight |
kg |
2450 |
|
Application:
electrical switchgear, transformers, power transmission industries copper, aluminum busbar chamfering or milling, avoiding the discharging of the rectangular copper / aluminum busbar.
