Help CenterISOEM-A2-P1-O6 Pocket Current Signal Electromagnetic Isolator Converter High-precision Amplifier 0-10mA Covert 1-5V
Related Products
-
ISOEM-A2-P1-O2 Pocket Current Signal Electromagnetic Isolator Converter High-precision Amplifier 0-1mA Covert 0-20mAUS$ 22 - 22MOQ: 10 Pieces -
ISOEM-A2-P1-O1 Pocket Current Signal Electromagnetic Isolator Converter High-precision Amplifier 0-1mA Covert 4-20mAUS$ 22 - 22MOQ: 10 Pieces
-
ISOEM-A3-P1-O1 Pocket Current Signal Electromagnetic Isolator Converter High-precision Amplifier 0-20mA Covert 4-20mAUS$ 22 - 22MOQ: 10 Pieces
-
ISOEM-A3-P1-O2 Pocket Current Signal Electromagnetic Isolator Converter High-precision Amplifier 0-20mA Covert 0-20mAUS$ 22 - 22MOQ: 10 Pieces
-
ISOEM-A3-P1-O4 Pocket Current Signal Electromagnetic Isolator Converter High-precision Amplifier 0-20mA Covert 0-5VUS$ 22 - 22MOQ: 10 Pieces
Product description
ISOEM Electromagnetic isolation converter,Low cost and small volume IC Package voltage current Converter Analog,The IC integrated high isolation DC/DC distribution power on the same chip,And the analog signal isolation amplifier multiple magnetoelectric coupling,Low cost scheme using magnetoelectric coupling,Mainly used for EMC (electromagnetic interference) no special requirements of the occasion.The input and output side of the wide range of the distance and the internal isolation measures to make the chip can reach the 3KVDC insulation voltage.Special occasions of use should pay attention to increase the electromagnetic interference suppression circuit or take the shielding measures.Very convenient to use,Without zero point and gain adjustment，No external zero,Gain adjustment potentiometer,Can realize the separation and conversion function of industrial field signal.
Product features
1.Signal input and output:0-5V/0-10V-0-75mV/0.2.5V/0-1mA/0-10mA/0-20mA/4-20mA
2.Accuracy 0.2%,Full range nonlinearity
3.power supply/input/output/Isolation 3000VDC
4.power supply:5V,12V,15V,24VDC,Power supply mode
5.No external potentiometer and other components Zero point and gain adjustment
6.Low cost and small volume,SIP-12 UL94V-0 standard flame retardant package
7.Industrial grade temperature range: -45 ~ +85℃
Typical application
--Accuracy class: 0.1 level, 0.2 level, the full range of nonlinear degree
--Low cost and small volume,SIP 12，UL94V-0 standard flame retardant package
--Adjustable zero and gain, full scale calibration of the multi ring potentiometer
--Current signal Conversion and amplification：0-1mA/±1mA/0-10mA/±10mA/0-20mA/±20mA/4-20mA
--Conversion and Amplification of Voltage Signals：0-75mV/0-2.5V/0-5V/0-10V/0-15V/0-10V/1-5V/±5V/±10V/±100mV
--Auxiliary power supply, input and output: 3000VDC three isolation
--Auxiliary power supply: 5V, 12V, 15V, 24VDC and other single power supply mode
--Industrial grade temperature range: -20 ~ +70
--Has strong anti EMC electromagnetic interference and high frequency signal spatial interference characteristics
--Pressure: 50Hz; 1 minutes; leakage current 1mA
--Impact resistance: 3KVAC, 1.2/50us (bee)
