Din Standard DIN3202-F1 Ductile Cast Iron y Flange Filter Valve PN10

Din Standard DIN3202-F1 Ductile Cast Iron y Flange Filter Valve PN10 thumbnail-1
Din Standard DIN3202-F1 Ductile Cast Iron y Flange Filter Valve PN10 thumbnail-2
Din Standard DIN3202-F1 Ductile Cast Iron y Flange Filter Valve PN10 thumbnail-3
Din Standard DIN3202-F1 Ductile Cast Iron y Flange Filter Valve PN10 thumbnail-4
Din Standard DIN3202-F1 Ductile Cast Iron y Flange Filter Valve PN10 thumbnail-5
Din Standard DIN3202-F1 Ductile Cast Iron y Flange Filter Valve PN10 photo-1
Din Standard DIN3202-F1 Ductile Cast Iron y Flange Filter Valve PN10 photo-2
Din Standard DIN3202-F1 Ductile Cast Iron y Flange Filter Valve PN10 photo-3
Din Standard DIN3202-F1 Ductile Cast Iron y Flange Filter Valve PN10 photo-4
Din Standard DIN3202-F1 Ductile Cast Iron y Flange Filter Valve PN10 photo-5
US$ 600 - 800 MOQ: 1 Ton
Key Specifications
Get Latest Price
Brand Name:
MDS
Place of Origin:
China
Application:
General
Contact Supplier Request Quote Chat Now
Shanxi Midas Industrial Co.,Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
TIANJIN,QINGDAO
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name MDS
Place of Origin China
Application General
Standard or Nonstandard Standard
Pressure Other
Power Other
Temperature of Media Other

din standard DIN3202-F1 ductile cast iron y flange filter valve PN10



Product Description



1 Size: DN25~DN300mm
2 Standard: DIN, BS, ANSI
3 Material: Ductile iron/cast iron
4 Working Pressure: PN6/PN10/PN16
5 Design: Face to face is according to BS5163: 1986
Flange drilled is according to BS4504
6 Media: Water, gas, oil, etc
7 Coating: Fusion bonded epoxy power coating
8 Brand Name: MDS
9 Sample: For free, but you need to bear their own delivery costs
10 Certificate: ISO, BV, SGS
11 Payment Term: T/T, L/C, D/P, etc
12 Package: Plywood boxes outside or as per customer’s requirement.
13 Delivery Time: 30 days after received the advance payment.





Material:

1 Body: Cast iron/ductile iron
2 Bonnet: Cast iron/ductile iron
3 Wedge: Ductile iron with NBR/EPDM
4 Stem: 2Cr13





Detailed Images

din standard DIN3202-F1 ductile cast iron y flange filter valve PN10.jpgy filter.jpg

DIN Standard DIN3202-F1 Ductile Cast Iron Water Y Strainer PN16.jpg

y strainer.jpg





Size



Size(DN) 25 32 40 50 65 80 100 125 150 200 250 300
L 160 180 200 230 290 310 350 400 480 600 730 850
H 105 115 130 140 150 175 230 260 300 360 440 525
