GENOX TWO SHAFT SHREDDER
M series two shaft shredders operate at low speed with high torque to minized noise and power consumption,whilst achieving high throughput rates.
This range of machines are particularly well suited to the size reduction of bulky or voluminous materials which can include contamination such as metals or stones.
Manufactured from heat treated 42CrMo high grade alloy,the blades present excellent wear and shock resistant properies.
Specifications
| model | M800T | M800 |
| Dimension L XW X H(mm) | 2930X1850X2200 | 2820X1060X1850 |
| Chamber size L X W(mm) | 800 X 750 | 800 X 480 |
| Discharge heath (mm) | 850 | 650 |
| Rotation diameter(mm) | Φ430 | Φ284 |
| Rotation speed(rpm) | 14.5 | 14 |
| Number of blades(pcs) | 20 | 40 |
| Blades thickness(mm) | 40 | 20 |
| Drive power(Kw) | 15+15 | 7.5+7.5 |
| Hopper volume(L) | 950 | 750 |
| Weight(Kg) | Approx 4300 | Approx 2200 |
With maintenance and operation taken into account during the design stage, the removal
and refitting of the blades is straight forward task. The machines are equipped with
mechanical and electrical overload protection systems, and can therefore be applied in
the processing of challenging materials such as WEEE (televisions, computers etc.), white
goods (washing machines & refrigerators), tires, drums, pallets, pipes to name but a few.
