Application
Gas Permeability Tester is based on the differential pressure method, and is professionally applicable to the determination of gas transmission rate as well as solubility coefficient, diffusion coefficient and permeability coefficient of plastic films, laminated films, high barrier materials, sheeting, metal foils, rubber, tires and permeable membranes.
Features
Vacuum differential pressure method
Own unique technology
3 specimens test simultaneously and independently
Computer control
One-button test, test automatically through whole process
High accuracy vacuum sensors embedded in
3 Chambers with independent temperature sensor
Test under various RH conditions with Humidity generator (optional)
Environment temperature and humidity sensor inside
Permeability coefficient ,solubility coefficient and diffusion coefficient test
Chambers with water bath temperature control technology
Unit based on embedded system,24bit Δ-Σ AD
Multiple test modes optional
Data curves display
Traceable reference film calibration
Supports DSM system (DSM, lab data management system)
Technical Indexes
A group test range: 0.01 - 600,000 cm3/m2·24h·0.1MPa (Standard)
B group test range: 0.001 - 50,000 cm3/m2·24h·0.1MPa (Standard)
Resolution: 0.001cm3/m2·24h·0.1MPa
Samples: 6, independent (A group 3 specimens, B group 3 specimens)
Vacuum accuracy: A group: 0.1Pa, B group 0.01
Temperature range: 5C - 95C
Temperature accuracy: ±0.1C
Humidity range: 0%RH,35%RH-90%RH,100%RH (optional)
Humidity accuracy: ±1%RH (optional)
Sample thickness: less 5mm
Sample size: >= 150mm * 94mm
Test area: 48cm2
Test gas: O2, N2, CO2, He, etc (self-provide)
Differential pressure: -0.1MPa - 0.1MPa
Gas interface: Ф8mm
Dimension: 1350mm(L) * 510mm(W) * 350mm(H)
Power supply: AC 220V 50Hz
Net wt.: 156kg
Standards
Gas Permeability Tester: ASTM D1434, ISO 15105-1,ISO 2556,GB/T 1038-2000,JIS 7126-1,YBB 00082003
Product Catalogues
What We Can Provide
Packages & Logistics
Export Area
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory. All instruments are R&D and Manufactured by SYSTESTER.
A: Generally it is 5 working days after we receive the payment or order confirmation.
A: At least 12 months. We can provide you lifelong technical support.
