Aluminum Profile Machine 2.2kw×2 Double Head Aluminium Cutting Machine

Aluminum Profile Machine 2.2kw×2 Double Head Aluminium Cutting Machine photo-1
Aluminum Profile Machine 2.2kw×2 Double Head Aluminium Cutting Machine photo-2
Aluminum Profile Machine 2.2kw×2 Double Head Aluminium Cutting Machine photo-3
US$ 3800 - 4000 MOQ: 1 Set
Key Specifications
Get Latest Price
After-sales Service Provided:
No overseas service provided
Warranty:
12 month
Certification:
Payment & Shipping
Payment Methods:
Port of Shipment:
Foshan
Delivery Detail:
15 days
After-sales Service Provided No overseas service provided
Warranty 12 month
Weight 430kg
Dimension(L*W*H) 1260×820×1390mm
Rated Power 2.2KW×2
Voltage 380V
Model Number MJ-350
Brand Name Haohongwei
Place of Origin China
Condition New

Parameter:

Sawing angle45º×2
Maximum sawing width100mm
Cutting height100mm
Spindle speed3800R/PM
Motor Power2.2KW×2
working pressure6kg/cm2
weight430kg
Saw blade sizeΦ355×Φ25.4mm×120T
working desk size1260×180mm
Dimensions1260×820×1390mm


Feature:

1.Just step on the foot pedal switch,the machine will pressure and cut the materials automatically,operation is safety and easy

2.Fast double blade sawing,save time and improve production efficiency

3.Any long or short material can be trimmed

4.Two sets of four oil sprayer provides proper lubrication to sawblade,spouting oil automatically when cutting,tangent plane is smooth,sawblade is long use life

5.Sawblade is driven by independent motor,powerful cutting

6.Apply upper and lateral pressure 2 group pressure material method,the materials become firmly established,pressure can be adjusted causes no deformation the hollow material

7.Install 2.4m feeding and discharging racks in the left and rght of the machine,discharging rack is equipped with positioning baffle makes set-inch cutting

8.Double sawblade device can finish 45° sawing on both ends of door and window frame at one time,convenient and efficient
