Features:
Composite hose is 40% lighter than the rubber hose which has the same diameter and length.
Excellent flexibility
Good positive and negative pressure resistance
Excellent corrosion resistance for chemical liquid medium
Outstanding flame retardant property
Anti-static
Long-term durability
The CCS and ABS certificates are available.
WIRE: Galvanised carbon steel inner wire (G)
Galvanised carbon steel outer wire (G)
also available with 304 Stainless Steel internal or external wires 316 on request
COLOUR: Blue/Black/Red
Parameter：
Model |
Internal diameter mm |
Bending radius mm |
Working pressure Mpa |
Burst pressure Mpa |
Length m |
Connection mode |
RGH25 |
25 |
150±5 |
2.5 |
10 |
1～40 |
customer requirements |
RGH40 |
40 |
190±5 |
2.5 |
10 |
1～40 |
customer requirements |
RGH50 |
50 |
210±5 |
2.5 |
10 |
1～40 |
customer requirements |
RGH80 |
80 |
300±5 |
2.5 |
10 |
1～40 |
customer requirements |
RGH100 |
100 |
350±5 |
2.5 |
10 |
1～40 |
customer requirements |
RGH125 |
125 |
420±5 |
2.5 |
10 |
1～40 |
customer requirements |
RGH150 |
150 |
558±5 |
2.5 |
10 |
1～40 |
customer requirements |
RGH200 |
200 |
705±5 |
2.5 |
10 |
1～40 |
customer requirements |
RGH250 |
250 |
851±5 |
2.5 |
10 |
1～20 |
customer requirements |
RGH300 |
300 |
1100±5 |
2.5 |
10 |
1～10 |
customer requirements |
RGH350 |
350 |
1250±5 |
2.5 |
10 |
1～10 |
customer requirements |
RGH400 |
400 |
1450±5 |
2.5 |
10 |
1～10 |
customer requirements |
