Name: 150G PCD & CBN Tool Grinder
Brief introduction : Grinding PCD,PCBN and CVD insert; carbide and HSS non-standard blades; standard or non-standard welding lathe tool, machine blades, boring cutter, grooving cutter and other various tools.
application: Grinding PCD,PCBN and CVD insert
Details
Introduction of PCD and PCBN Tool Grinder:
150G PCD and CBN Tool Grinders are reliable in performance and easy to be operated. It requests very little manual skill and can grind PCD, PCBN and CVD insert; it can also grind carbide and HSS non-standard blades, standard or non-standard welding lathe tool, machine blades, boring cutter, grooving cutter and other various tools.
Features of PCD and PCBN Tool Grinder:
Mechanical Structure: The Base Of Machine Is Made Of Solid Casting With High Quality. It Can Meet Grinding Requirements Of Any Hard Material.
Grinding Spindle: With High Precision And Variable Frequency, The Direct-Drive Spindle Power Is 3Kw; Max Speed Is 4000r/Min
The Inner Of Spindle Is Co Oled By Recycling Water. The Radial Run-Out Is 0.003mm And Axial Run-Out Is 0.0025mm.
Feed Wheel: The Feed Wheel Includes Rapid Feed And Precision Feed. The Feed Rate Is 0.5mm/Turns And Feed 3mm/Turn Respectively.
Main Technical Parameters of PCD and PCBN Tool Grinder:
spindle and grinding wheel | |
diameter of grinding wheels |
150 mm |
power of spidle |
3 KW |
rpm of grinding spidle |
0- 4000 RPM |
changeable clearance angle |
-5 ° - 25 ° |
grinding wheel center hole |
40 mm |
FAQ:
Q1. Can I negotiate the price
A: yes, you can. We will give some discount according to your quantity.
Q2. How can know my order’s production progress?
A: we will keep closely track the production and shipment progress. And we will inform you with the newest progress about producing and shipping.
Q3. How can you ensure the quality of your products?
A: We have pass the ISO 9001:2008. If there is any problem with our products, please send me the detailed picture of the problem, once we verify it, we will change the products for you within 30 days.
Q4: When I contact you is suitable?
You can contact Us at any time, we promise that we will reply you within 12 hours.
A:So, please contact me for more information about our product, service and related issues.
Our products Range:
1. vitrified bond/resin bond/Metal bond/Electroplated diamond grinding wheel & other diamond tools
2. PCD milling tools, pcd turning tools, pcd drilling tools, pcd engraving tools,pcd/pcbn inserts, pcd/pcbn cutting tools, pcd/pcbn grooving tools,CBN inserts
3. PCD/TSP diamond, CVD diamond tools, Natural diamond tools, diamond abrasive tools
4. diamond grinding&cutting discs, diamond cutting blade, diamond cup wheel, diamond dressers
5. Roller cutting tools, PDC cutters, pdc drill bits& pdc core bits
6. PCD tool grinder & pcd grinding machine
Please don't hesitate to contact me if you have any needs:
Email:miya@moresuperhard.com
WhatsApp:+8618614972607
Skype:Miya M
Wechat:18614972607
Our company also produces a series of diamond and CBN tools,welcome to consult and choose at any time
