22B-D012N104 PowerFlex 40- 5.5 kW (7.5 HP) AC Drive

PowerFlex 40 AC Drives

PowerFlex  40 AC Drives provide OEMs, machine builders,

 and end users with performance-enhancing motor control

in an easy-to-use compact package.

These  drives feature sensorless vector control to meet low-speed torque demands.

With flexible enclosure options, and simple programming, t

hey can be installed and configured quickly. We also have

 packaged drives that provide additional control, power,

and enclosure options in standardized designs.

22B-D1P4N104  PowerFlex 40- 0.4 kW (0.5 HP) AC Drive

22B-D1P4C104  PowerFlex 40- 0.4 kW (0.5 HP) AC Drive

22B-D2P3N104  PowerFlex 40- 0.75 kW (1 HP) AC Drive

22B-D2P3F104   PowerFlex 40 0.75 kW (1 Hp) AC Drive

22B-D4P0N104  PowerFlex 40- 1.5 kW (2 HP) AC Drive

22B-D4P0F104  PowerFlex 40 1.5 kW (2 Hp) AC Drive

22B-D6P0C104  PowerFlex 40- 2.2 kW (3 HP) AC Drive

22B-D6P0N104  PowerFlex 40- 2.2 kW (3 HP) AC Drive

22B-D010N104  PowerFlex 40- 4 kW (5 HP) AC Drive

22B-D012N104  PowerFlex 40- 5.5 kW (7.5 HP) AC Drive

22B-D017N104  PowerFlex 40- 7.5 kW (10 HP) AC Drive

22B-D024N104  PowerFlex 40- 7.5 kW (10 HP) AC Drive

Features

1.Power ratings: ?100...120V: 0.4...1.1 kW / 0.5...1.5 Hp / 2.3...6 A

2.200...240V: 0.4...7.5 kW / 0.5...10 Hp / 2.3...33 A

3.380...480V: 0.4...11 kW / 0.5...15 Hp / 1.4...24 A

4.500...600V: 0.75...11 kW / 1...15 Hp / 1.7...19 A

1.IP20 NEMA/UL Type Open, plate drive, flange mount, IP66 NEMA/UL Type 4X/12, and DIN rail

2.Optional IP30 NEMA/UL Type 1 conversion kit

3.Ambient temperatures up to 50 °C (122 °F) permitted with minimal spacing between drives

4.Zero Stacking? Drives for ambient temperatures up to 40 °C (104°F)

5.V/Hz and sensorless vector control, as well as process PID

6.Integral RS-485 communication

7.Optional serial converter module for use with any controller with DF1 messaging

8.Optional DeviceNet?, ControlNet?, and EtherNet/IP?, Profibus DP, BACnet?, and LonWorks? communication modules

9.Drive overload protection, ramp regulation, and flying start

10.StepLogic? allows operation as an independent position controller

11.Configuration and programming via integral LCD keypad, remote keypad, or software

12.Premier Integration with PowerFlex? AC drives uses the Logix control platform to simplify parameter and tag programming and reduce development time

Packaged Drive Options

13Power options include circuit breaker, fused disconnect, bypass, and input fuses

14.Output relay and transformer control options

15.Door-mounted human interface module (HIM), hand/off/auto selector switch, status pilot lights, and speed potentiometer
