Pet Treats Forming Machine
Pet Food Machine
Pet Treats Forming Machine can produce dog’s jerky treats with high-content meat.
Advantages of Pet Treats Forming Equipment:
1.This machine can automatically finish the procedures: feeding materials - forming - shaping.
2.This machine shares the reputation of high automatlization, mini size and easy operation, very simple cleaning design.
3.The whole machine is made by 304 stainless steel, and SIEMENS electric motor.
4.This machine can process diversified materials: meat, poultry, beef, mutton, seafood, fish, shrimp, vegetable, pumpkin, potato, cheese or their mixture.
5.Various sizes can be made.
6.Various production procedures can be combined for producing many kinds of different end-products.
7.It regularly becomes the most ideal for the small or middle scale factory, home factory and dispatching center.
Application Scope:
Technical Parameters of :
Model |
QL-200 |
QL-400 |
QL-600 |
Power |
0.55kw |
12kw |
15kw |
Max. output |
40-50kg/hr |
500-600kg/hr |
1000-1200kg/hr |
Speed |
15-30times/min |
15-55times/min |
15-60 times/min |
Patty thickness |
6-18mm |
6-20mm |
6-40mm |
Max. patty diameter |
95mm |
135mm |
150mm |
Patty weight error |
≤1% |
≤1% |
≤1% |
Tank Volume |
32L |
150L |
200L |
Raw material type |
Versatile |
Versatile |
Versatile |
Filling pressure |
Mechanical type |
3-15Mpa |
3-15Mpa |
Weight |
90kg |
1100kg |
1500kg |
Dimension |
715 x 600 x 1400mm |
2828 x 830 x 2136mm |
3170 x 1180 x 2440mm |
