BXZ-1 Backpack rig / knapsack sampling drill/ Portable core drilling rig
- 100 Set / Sets per Month
- qingdao
- T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
- 7 days
- China Xy-200 Water Well Drill Rig Machine for Soil and Rock Drilling
- 100 Meters Xy-1A Water Well Drilling Rig Machine Equipment
- HY-50H Small Domestic Hydraulic Water Well Drilling Rig of China
- 50m Depth Core Drilling Rig Portable Diamond in Mountain
- TSP core bit, BQ NQ HQ PQ core drill bits, HWL, wireline core barrels, diamond coring bits, hard formation, deep hole rock core recovery
- 1.5M 3M inner tube assembly, wireline core barrels, head assembly, impregnated diamond drilling, hard formation coring, deep hole rock core recovery
Product Details
Brand Name: | HuaxiaMaster | Place of Origin: | China | Model Number: | BXZ-1 |
Type: | Core Drilling Rig | After-sales Service Provided: | Engineers available to service machinery overseas | Power Type: | Diesel |
Usage: | Coal | Condition: | New | Power(W): | diesel engine |
Product Description
1.The range of application of backpack rig
BXZ-1 backpack rig is used for core exploration、geological research and prospectors, it has experienced decades of experience and accumulation in dozens of countries and regions in the world of the field validation, Shandong Master Machinery Group Co.,Ltd We constantly improve and upgrade the quality of backpack rig and believe that the equipment will be helpful for your work.
2.The main charateristic of backpack rig
a. All the drilling equipment can be carried by a single person.
b. A whole set of backpack drilling rig and spare parts can be putted into a backpack, the backpack easy for one person to take away.
c. The operation is flexible as long as simply rotate and push and pull, no additional tools, can be linked or extend the whole device, easy disassembly drag. Coupled with the core draw, can quickly and thoroughly remove core and core fragments.
d. The drilling rig is easy to assemble and disassemble, and the machine can be operated simply
g. Quick drilling, our drilling rig is a patented product in China, drill through a variety of rock surface efficiency is unique, special formula of diamond bit has a sharp notch, save time and effort, and ensure the service life of enough.
3.The packing list of backpack portable core drilling machine
Name | Mode | Unit | Quantity |
Drilling rig | 3.2hp/Mitsubishi | set | 1 |
Drill pipe | 33*800mm | pcs | 28 |
Drill joint | 33*100mm | pcs | 28 |
Core barrel | 33*600mm | pcs | 1 |
Core barrel joint | pcs | 1 | |
Alloy bit | 33mm | pcs | 1 |
Compact bit | 33mm | pcs | 1 |
Diamond bit | 33mm | pcs | 1 |
Hand pressure bottle | set | 1 | |
Gasoline mud pump | high pressure | set | 1 |
Service aid | gasoline | set | 1 |
Mud pump suction pipe | set | 1 | |
Mud pump suction faucet | pcs | 1 | |
Drill rig flow pipe | set | 1 | |
The ratio of pot | pcs | 1 | |
U-fork | pcs | 1 | |
UL-fork | pcs | 1 | |
Pipe wrench | pcs | 1 | |
Backpack | pcs | 1 |
