SX600 high carbon steel wire arc coating machine, screw coating equipment , 1.6~3.2mm zinc aluminum copper arc wire spray machine with factory price
- 50 Piece / Pieces per Month
- guangzhou
- T/T
- Hand wheel operated PTFE Lined Diaphragm Valve
- BS Standard Manual PTFE Lined Diaphragm Valve
- Manual Fluorine Lined Diaphragm Valve
- Stainless Steel Type Pneumatic Ceramic Double Disc Gate Valve
- 5 Inch Class 150 Stainless Steel Pneumatic Ceramic Double Disc Gate Valve
- Anti Corrosive and Abrasive Type Pneumatic Ceramic Double Disc Gate Valve
Product Details
Brand Name: | SANXIN | Place of Origin: | China | Model Number: | SX600 |
After-sales Service Provided: | Engineers available to service machinery overseas | Condition: | New |
Product Description
SX600 high carbon steel wire arc coating machine, screw coating equipment , 1.6~3.2mm zinc aluminum copper arc wire spray machine with factory price
SX-600 is one kind of zinc aluminum copper arc coating machine, screw coating machine , arc spray machine with arc spray gun ,it is used for spraying zinc, aluminum, copper, molybdnum, titanium,stainless steel,high carbon steel,nickel chromium alloy,wear-resistant alloy,Babbitt alloy material,etc.
1.principle of SX600 high carbon steel wire arc coating machine, screw coating equipment , 1.6~3.2mm zinc aluminum copper arc wire spray machine with factory price
This high velocity arc spraying (high velocity arc spraying) is a technology which uses arc to melt metal,the arc is formed by combustion in two continuous feeding metal wire,then the melting metal is atomized by high speed airflow.Through the laval nozzle,the atomizing metal particles are accelerated to make them to exceed supersonic to spray to the workpieces to form a coating
2. component of SX600 high carbon steel wire arc coating machine, screw coating equipment , 1.6~3.2mm zinc aluminum copper arc wire spray machine with factory price
It is a new technology based on the normal arc spraying ,which is composed of a special power supply, an arc spray gun, a push type arc spraying device, and a wire feeder.
(1)control cabinet
(2) arc spray gun
3. parameter of SX600 high carbon steel wire arc coating machine, screw coating equipment , 1.6~3.2mm zinc aluminum copper arc wire spray machine with factory price
Arc spray gun parameters:
Model | Arc spray gun |
Operation mode | Handed or fixed |
Input voltage | ≤24V(DC) |
Applied wire diameter | Φ1.2 Φ1.6 Φ2.0 Φ3.0 mm |
Air pressure | >0.5Mpa |
Air consuming | >1.85m3/min |
Wire feeding gravitation | >8kg |
Feeding velocity regulating grade | Stepless speed regulating |
Weight | 2.65kg |
Metal wire parameters:
Spray material | Wire diameter | Working current | No-load volt | Air hat diameter | Maximum spray efficiency |
Zinc wire | 1.2-3.0 | 80-210 | 18-30 | 6-8 | 30 |
Al wire | 1.2-3.0 | 120-240 | 25-38 | 6-8 | 9.5 |
Steel wire | 2.0 | 150-200 | 35-40 | 7-8 | 6 |
High carbon steel wire | 2.0 | 150-220 | 10-44 | 8 | 5.5 |
Stainless steel wire | 2.0 | 150-220 | 10-44 | 8 | 5.5 |
Zn-Al, Pb-Sn alloy wire | 1.2-2.0 | 80-110 | 18-28 | 7 |
4.advantage of SX600 high carbon steel wire arc coating machine, screw coating equipment , 1.6~3.2mm zinc aluminum copper arc wire spray machine with factory price
1) Stable and convenient
This equipment is improved in the operation program by integrated circuit to prevent from machine damage by misoperation of workers, so as to protect the safety of operators and the equipment.
2) High adhesive force of coating(70Mpa)
Compared with 30-40Mpa of common arc’s coating,the adhesive force of coating can reach 70Mpa.
3) Workpiece won’t be deformed and its structure won’t be changed.(<100℃)
Generally the rised temperature of workpiece won't exceed 100 ℃ when spraying, so the workpiece won't be deformed. And the spraying heat won't take effect directly on the surface so it doesn’t change the structure of workpiece.
4) High efficiency and wide application
The equipment has high spray efficient and high power; It's suitable for on-site construction, and can use all kinds of metal and metal ceramic materials(solid and without core), such as alloy wires, Mo, Al, Zn, red copper, copper alloy, Babbitt etc. It is widely applied in spraying anti-wearing and anti-rust coatings for boiler’s four kinds of tubes, coal pulverizing system (fan impeller and scroll casing), roller, dryer, axis, mould,all kinds of workpieces and so on.
5)Spray gun for long distance(30-meter-long-cable)
The spray gun can be equipped with 30-meter-long cable, air tube and 8-core control cable, so it can spray at remote places about 30 meters from the equipment.
6)Unnecessary to change the wearing parts frequently
We have patent conductive nozzle which is anti-wearing and greatly enlarges use time of wearing parts. This helps to reduce the spraying cost and improve working’s efficiency and coating’s quality.
7)Convenient maintainance and repair
We take maintainance and repair work into our consideration during designing the equipment and spray gun which make it convenient to maintain and repair.
5.SX600 high carbon steel wire arc coating machine, screw coating equipment , 1.6~3.2mm zinc aluminum copper arc wire spray machine with factory price for example:
Also, arc spray coating machine SX600 can spray zinc or aluminum on the metal chairs ,metal facilities in the garden ,to improve the wear resistant ,wear corrosion of them, so as to lengthen their usage life .
6.our products and customers :
our products are taken strict quality control ,Our customers are from a lot of countries in the world, we have established long term cooperation with them.SX600 is the best sellers in our company , with good quality,wide usage and low price
Our factory is committed to spraying technology research for more than 30 years ,we have dozens of spraying equipment ,such as thermal spraying equipment,arc spray coating machine, plasma spraying equipment ,and so on.
We also have various kinds of other spray equipments ,If you are interested in ,please contact me :
