Black 3D Curved PVC Coated 50x200mm Weled Mesh Fence Panel
Galvanized and coated welded wire meshes manfuactured in modular panels are used for easy setting up of mobile and security fencing system. It is widely used as airport fence, railway fencing, machine protective shield, border fencing as well as various commercial fencing uses.
Welded wire fabric is made of high-quality low-carbon steel wire. Processing includes rowing welding, cold galvanizing (electroplating) or hot-dip coating, PVC or PE-coating.
Features
Smooth surface, uniform mesh, firm welding spots, excellent machining performance, good stability, corrosion protection and multi-purpose applications.
Varieties
Pre-galvanized welded mesh;
Hot dipped galvanized welded mesh after welding;
Galvanized welded mesh, finished with powder coating on the surface.
Wire Materials: With PVC coating, anti-violet and anti-aging auxiliary agent can be added in the coating materials.
Characteristics:
PVC Coated Welded Mesh Panels offer excellent characteristics such as corrosion resistance, oxidation resistance, acid resistance, alkali resistance, aging resistance, sunshine resistance and weather resistance. Besides this kind of product has flat even surface and strong structure, therefore this product has a long service life. Moreover the coated layer is even, strong adhesiveness and bright luster.
Applications:
PVC Coated Welded Mesh Panel with excellent characteristics is extensively used in the construction of chain link fences for industrial security fences, freeways and tennis courts. It is also used in other applications such as coat hangers and handles. Suitable for houses and properties, companies, gardens recreation area sparks.
| Item | Wire Gauge (SWG) | Opening (inch) | Length (m) | Width (m) | Weight (kg) |
|---|---|---|---|---|---|
| PWPS-01 | 8 | 4.06 | 2 | 4 | 4.25 |
| PWPS-02 | 9 | 3.65 | 2 | 4 | 3.45 |
| PWPS-03 | 10 | 3.25 | 2 | 4 | 2.74 |
| PWPS-04 | 11 | 2.95 | 2 | 4 | 2.25 |
| PWPS-05 | 12 | 2.65 | 2 | 3 | 1.80 |
| PWPS-06 | 13 | 2.34 | 2 | 3 | 1.40 |
| PWPS-07 | 14 | 2.03 | 2 | 3 | 1.08 |
The most popular products and specifications
All electro galvanized after welding (bright), 2 m × 2.5 m panels, 1/2" × 2", 2.0 mm wire, 3" × 3", 3.0 mm wire, 3" × 6", 5 mm wire. Fence with three bends along the panel 2" × 6", 5 mm wire, finished with green paint.
Black PVC coated panels with 1" mesh opening, 2 mm wire. 100" × 450", 700" × 450" for rabbit hutch.
Black PVC coated wire mesh 1" × 1" × 48" × 96" sheets.
PVC coated welded mesh panels (three weaves), panel size 2500 mm × 2000 mm, mesh size 60 mm × 150 mm.
PVC coated 2' × 6' panels in red for use in garden.
1" × 1" × 4' × 8' powder coated white panels used in deck railing.
1.8 m high fencing panels – PVC coated welded mesh panels.
PVC coated wire welded mesh in black with 1/2" × 1/2" squares mesh, 39" × 39" and 108" × 36" panels.
PVC fences 3200 mm × 2018 mm with the following dimensions:
Mesh: 70 mm × 200 mm.
Diameter: 5 mm × 7 mm.
Pole: Galvanized 80 mm × 40 mm × 5.5 mm, 3700 mm high.
Green PVC coated.
The connection is made with galvanized flange PVC coated green joined with tamperproof screw.
PVC blacked coated wire mesh which is used for fishing catch in the sea
1" × 19 gauge after PVC coated (0.60 mm electric galvanized inner wire + 0.40 mm black PVC thickness) 1 m × 50 m.
1-1/4" × 18 gauge after PVC coated (0.70 mm electric galvanized inner wire + 0.40 mm black PVC thickness) 1 m × 50 m.
1-1/2" × 18 gauge after PVC coated (0.70 mm electric galvanized inner wire + 0.40 mm black PVC thickness) 1 m × 50 m.
