Stringer Pallet Nailing Machine
1. The automatic wood pallet nail machine equipment including auto stacking platform , wood pallet lifting device and flip picking device .
2. High Degree automation , smooth closely process , complete nailing and stacking in one time .
3. The whole machine use full automatic system , PLC control , simple touch screen operation , accurate pinning position with high efficiency .
Technical parameters
Product name |
Automatic wooden pallet making machine |
Model |
YPM-1300 |
Working mode |
Automatic feeding of automatic nail stacking |
Operation mode |
PLC Control |
Operational mode |
Pneumatic operation |
Voltage and power |
380V three-phase 1.5kw Servo motor |
Air pressure |
0.8MPA |
Tank size |
0.2 cubic |
Nail gun speed |
7 times /second. |
Production efficiency |
3 tray /min |
Apply a nail |
Less than 80mm |
Weight |
2000kg |
Size |
Host machine 2000*2800*2600mm Stacking 2600*1900*1600 |
Operation program :The machine used touch screen control with advanced programming .Feeding mechanism and nailing machine multi-axis linkage at the same time when working . It works fast and efficient . One more thing , it could switch different program basis on plate of different material to produce non-standard pallet .
