SH-120 Corrosion Test Chamber

Name: SH-120 Corrosion Test Chamber
Brand: ASLI
SKU: 158999544
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

ASLI

Place of Origin:

China

AI SI LI (China) Test Equipment Co., Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Brand Name ASLI

Place of Origin China

SH-120 Corrosion test chamber

Salt Spray Test Chamber

Salt Spray Corrosion Test Chamber

Application:

Salt Spray Corrosion Test Chamber is specially designed for the testing of the corrosion erosion resistance of the products after their material

surfaces have been treated with electric plating, anodizing, spray coating, anti-rusting oil and other anti-erosion treatment.

Features:

1. Adopt automatically or manually adding water system, can watered by itself while lack of water.

2. Precise glass spray nozzle, good uniformity, mist dropping naturally, no NaCl crystallized salt

3. Double over-heat protection devise and alarm when water short storage to ensure use safety.

4. Digitally temperature controller, PID controlled, precision of ±0.1℃

5. Laboratory direct steam-heated, even heating speed, reducing the standby time.

6. Tapered Spray tower, even mist dropping

7. Saturated bucket is SUS #304, convenient for heating and humidifying, offer humidity for testing

8. Concentration of NaCl: 5%;PH of the water:6.5-7.2 (Liquid)

Technical Parameters:

Model	SH-120
Internal Dimension	W1200xH500xD800 (mm)
External Dimension	W1900xH1300xD1000 (mm)
Lab Temperature	Saline test (NSS ACSS) 35±1 ℃ / Corrosion Test (CASS) 50±1 ℃
Pressure Bucket Temperature	Saline test method (NSS ACSS) 47±1 ℃ / Corrosion Test (CASS) 63±1 ℃
Lab Capacity(L)	500
Saline Capacity(L)	40
Saline Concentration	5% concentration of NaCl, or every Liter 5% NaCl add 0.26g CuCl2H2O
Compressed Air Pressure(Kgf)	1.0~6.0
Spray Volume	1.0~2.0ml /80cm2 /h (working at least 16 hours, and take the average value)
Spray Form	Continuous Spraying or Programmable Spraying
Power	AC 220V, 1∮ 3 lines15A
Weight(Kg)	250
