Main parameters:
Vehicle series |
HOWO-7 4x2 Highway Tractor |
||
Cab |
HW76/HW79 |
||
Engine |
Model |
WD615.69;WD615.47;WD615.95C,D10.34-40/50; WD615.96C,D10.38-40/50 |
|
Power(Ps /rpm) |
246/2200;272/2200;249/1900;279/2000 |
||
Maximum torque(Nm/rpm) |
1350/1100-1600;1500/1100-1600;1490/1200-1500;1590/1200-1500 |
||
Displacement(L) |
9.726 |
||
Transmission |
SINOTRUK HW series 10 gears Transmission, main and auxiliary transmission structure, main transmission with double counter shaft ,auxiliary transmission with planetary reduction. standardHW19710,optional HW19710T |
||
Clutch |
Φ430diaphragm spring Clutch,Hydraulic control air assisted. standard CH430-21 |
||
Front axle |
HF7,rated load of 7t, drum-type,disc-type is optional |
||
Rear axle |
MCY13 Single reduction,speed ratio:4.11,3.7,3.36 ;optional ST16 |
||
Steering gear |
Bosch steering gear, system pressure 18MPa |
||
Suspension |
Steer Axle |
front and rear leaf spring suspension+shock absorber , transverse stabilizer |
|
Drive Axle |
front and rear leaf spring suspension+shock absorber , transverse stabilizer |
||
Braking system |
Service brake |
dual-circuit air pressure brake |
|
Parking Brake |
spring storage energy without air |
||
Auxiliary brake |
Engine exhaust braking. standard Engine EVB,ABS, optional auto clearance adjusting arm. |
||
Electric system |
Voltage |
24V |
|
Generator |
2KW |
||
Batteries |
12V/165Ah,2 pieces |
||
Starter Power |
24V,7.5KW |
||
Wheels & Tyres |
Tyres |
315/80R22.5 |
|
optional |
12.00R20; 12R22.5 |
||
Fuel Tank |
Capacity |
400 Liters |
|
Weights (kg) |
Curb weight |
7100 |
|
Gross Vehicle Weight |
49000 |
||
Design loading capacity at fifth wheel |
10770 |
||
Maximum traction weight |
41900 |
||
Vehicle Dimensions (mm) |
Overall length x width x height without deflector |
6125x2496x3125/3730 |
|
Wheelbase |
3500 |
||
Front overhang/Rear overhang |
1500/1125 |
||
Wheel track of front axle |
2022 |
||
Wheel track of rear axle |
1830 |
||
Performance |
Maximum speed(km/h) |
99/104 |
|
Maximum gradeability(%) |
20 |
||
Minimum turning diameter(mm) |
14 |
||
Our services:
1,Competitive price--We work as the construction machinery company for more than 30 years,we have a good relationship for most of the parts on heavy machine market.The feedback from most of our clients that our price is more competitive than others.
2,Quick response--Our company serve our customers as the best friend all the time,we always response customers inquiries and questions in the first time. Most problems can be solved withing 12 hours.
3,Fast delivery--We have a variety of resources to help us to give our customer an immediately delivery compare with other factories for more than 15 days to produce the ordered machine.
FAQ：
1， What’s your MOQ?
Minimum order is 1 pc only, dealership is warmest welcome.
2，What’s the qualify assurance we provided and how do we control quality?
1. Established a procedure to check products at all stages of the manufacturing process from raw materials to final products. Beside, we have also developed a procedure which identifies the inspection and test status of all items at all stages of the manufacturing process.
2.100% inspection in assembly lines. All controls, inspections,equipment,fixtures,total production resources and skills are inspected to ensure they consistently achieve the required quality levels.
3， How do you transport the trucks?
We transport the vehicle in nude or Polish with wax before shipping.
Our company has long -term cooperation with ship agency which can provide you lowest shipping fee.
4, Can you satisfy my special requirement?
Yes, We can make customized design to utmost meet your special requirements.
