X6036W Knee Type Milling Machine

X6036W Knee Type Milling Machine thumbnail-1
X6036W Knee Type Milling Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Sanmore
Place of Origin:
China
Model Number:
X6036W
Contact Supplier Request Quote Chat Now
Shaanxi Sanmore Industry And Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or other China port
Delivery Detail:
50 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Sanmore
Place of Origin China
Model Number X6036W
Type Vertical
After-sales Service Provided Engineers available to service machinery overseas
Condition New
CNC or Not Normal

X6036W Knee Type Milling Machine is a horizontal milling machine, power feed on two axes, motorized lift on Z axis, three axes hardened, steel-type strong, good stability.

Model

X6036W

Spindle taper

7:24    ISO50

Distance from   spindle nose to table  (mm)

0-440

Distance from   spindle axis to arm (mm)

170

Spindle speed   range (r. p. m)

60-1700    12 steps

Table size

1250×360

Table travel

Horizontal   (mm)

600

Cross (mm)

320

Vertical

400

Range of   longitudinal cross travel

30-740mm/min 8   steps  1080mm/min (rapid)

Z speed of   table

590 mm/min

T-slot of   table (number-width-length)

3-18-80

Main motor   power

4KW

Motor for   rapid device of table (X, Y)

750 W

Motor for   vertical device of table (Z)

750 W

Overall   dimensions

1880×1700×1700

Net   Weight/Gross Weight

1850×1950




Product Tags: Vertical milling machine , Upright milling machine , Knee-type milling machine
