Description
YDPB is professional on the bearings inlcude Kaydon standard think section bearings ,THK IKO
standard crossed roller bearings,INA standard Rotary Table bearings ,and also with many stock ones
flexible deep groove ball bearings used for harmonic drive, custom made bearings avaible.
Kaydon thin-section bearings Structure
Open type deep groove ball bearing
Open type angular contact bearing
Open type four point contact bearing
Sealed type deep groove ball bearing
Sealed four point contact ball bearing
Feature
1. compact structure, light weight, low vibration and friction
2. high precision,
3. space and cost saving
4. best quality, long life
Main parameters
| YDKF Series | Interchange | Boundary dimensions (inch/mm) | Basic Cap.N | Weight | ||||||
| Bearings Type | NTN | KAYDON | d | D | H | L1 | L2 | Cor | Cr | Kg |
| 177.8 | 215.9 | 19.05 | 191.9 | 201.8 | ||||||
| YDKF075CP0 | KRF075 | KF075CP0 | 7.5 | 9 | 0.75 | 8.055 | 8.445 | 41380 | 21300 | 1.56 |
| 190.5 | 228.6 | 19.05 | 204.6 | 214.5 | ||||||
| YDKF080CP0 | KRF080 | KF080CP0 | 8 | 9.5 | 0.75 | 8.555 | 8.945 | 43920 | 22000 | 1.66 |
| 203.2 | 241.3 | 19.05 | 217.3 | 227.2 | ||||||
| YDKF090CP0 | KRF090 | KF090CP0 | 9 | 10.5 | 0.75 | 9.555 | 9.945 | 48900 | 23370 | 1.81 |
| 228.6 | 266.7 | 19.05 | 242.7 | 252.6 | ||||||
| YDKF100CP0 | KRF100 | KF100CP0 | 10 | 11.5 | 0.75 | 10.555 | 10.945 | 53920 | 24680 | 2.02 |
| 254 | 292.1 | 19.05 | 268.1 | 278 | ||||||
| YDKF110CP0 | KRF110 | KF110CP0 | 11 | 12.5 | 0.75 | 11.555 | 11.945 | 58940 | 25930 | 2.18 |
| 279.4 | 317.5 | 19.05 | 293.5 | 303.4 | ||||||
| YDKF120CP0 | KRF120 | KF120CP0 | 12 | 13.5 | 0.75 | 12.555 | 12.945 | 63960 | 27140 | 2.38 |
| 304.8 | 342.9 | 19.05 | 318.9 | 328.3 | ||||||
Application
Aerospace and defense
Astronomy instrumentation
Fixturing and workholding equipment
Food processing equipment
Glassworking equipment
Index and rotary tables
Packaging equipment
Machine tools
Medical systems and medical devices
Optical scanning equipment
Tire making equipment
china thin section bearings suppliers
china thin section bearings
slewing bearing made in china
cross roller bearing factory
china rotary table bearing suppliers
china robot bearing suppliers
Models list
Open type thin section kaydon deep groove ball bearing:
KA020CP0, KA025CP0, KA030CP0, KA035CP0, KA040CP0, KA042CP0, KA045CP0, KA047CP0, KA050CP0, KA055CP0, KA060CP0, KA065CP0, KA070CP0, KA075CP0, KA080CP0, KA090CP0, KA100CP0, KA110CP0, KA120CP0,
KB020CP0, KB025CP0, KB030CP0, KB035CP0, KB040CP0, KB042CP0, KB045CP0, KB047CP0, KB050CP0, KB055CP0, KB060CP0, KB065CP0, KB070CP0, KB075CP0, KB080CP0, KB090CP0, KB100CP0, KB110CP0, KB120CP0, KB140CP0, KB160CP0, KB180CP0, KB200CP0,
KC040CP0, KC042CP0, KC045CP0, KC047CP0, KC050CP0, KC055CP0, KC060CP0, KC065CP0, KC070CP0, KC075CP0, KC080CP0, KC090CP0, KC100CP0, KC110CP0, KC120CP0, KC140CP0, KC160CP0, KC180CP0, KC200CP0,
KD040CP0, KD042CP0, KD045CP0, KD047CP0, KD050CP0, KD055CP0, KD060CP0, KD065CP0, KD070CP0, KD075CP0, KD080CP0, KD090CP0, KD100CP0, KD110CP0, KD120CP0, KD140CP0, KD160CP0, KD180CP0, KD200CP0,
KF040CP0, KF042CP0, KF045CP0, KF047CP0, KF050CP0, KF055CP0, KF060CP0, KF065CP0, KF070CP0, KF075CP0, KF080CP0, KF090CP0, KF100CP0, KF110CP0, KF120CP0, KF140CP0, KF160CP0, KF180CP0, KF200CP0,
KG040CP0, KG042CP0, KG045CP0, KG047CP0, KG050CP0, KG055CP0, KG060CP0, KG065CP0, KG070CP0, KG075CP0, KG080CP0, KG090CP0, KG100CP0, KG110CP0, KG120CP0, KG140CP0, KG160CP0, KG180CP0, KG200CP0,
Sealed type thin section kaydon deep groove ball bearing:
JA020CP0, JA025CP0, JA030CP0, JA035CP0, JA040CP0, JA042CP0, JA045CP0, JA047CP0, JA050CP0, JA055CP0, JA060CP0, JA065CP0,
JB020CP0, JB025CP0, JB030CP0, JB035CP0, JB040CP0, JB042CP0, JB045CP0, JB047CP0, JB050CP0, JB055CP0, JB060CP0, JB065CP0,
JU040CP0, JU042CP0, JU045CP0, JU047CP0, JU050CP0, JU055CP0, JU060CP0, JU065CP0, JU070CP0, JU075CP0, JU080CP0, JU090CP0, JU100CP0, JU110CP0, JU120CP0,
JG120CP0, JG140CP0, JG160CP0, JG180CP0, JG200CP0
