India Stainless Steel Wire Mesh Weaving Machine
US$ 10000 - 30000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
shijiazhuang highui
Place of Origin:
China
Model Number:
China CNC shuttleless machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin ,china
Delivery Detail:
45 days
Related Products
-
16mesh0.45mm Stainless Steel Wire Mesh MachineUS$ 10000 - 30000MOQ: 1 Set -
CNC Shuttleless Stainless Steel Wire Mesh Making MachineUS$ 10000 - 30000MOQ: 1 Set
-
Shuttleless Loom Wire Mesh Machine ( Manufacturer)US$ 10000 - 30000MOQ: 1 Set
-
China CNC Non- Shuttle Metal Wire Mesh Weaving Machine ManufactureUS$ 10000 - 30000MOQ: 1 Set
-
1600mm Shuttleless Plc Control Weaving Mesh Machine for Stainless Steel Wire MeshUS$ 10000 - 30000MOQ: 1 Set
Brand Name
shijiazhuang highui
Place of Origin
China
Model Number
China CNC shuttleless machine
After-sales Service Provided
Engineers available to service machinery overseas
Condition
New
Note: we focus on advanced machine research since 1981
Why we are different ?
1. We offer forever technology support & spare parts available for after sales
2. Our engineer is always go abroad to set machine, train local engineer, train workers how to weave perfect mesh
3. With many years machine research our machine type - light, medium heavy, heavy and big machine for different mesh and thick, thin wire
| Width MM |
Opening density (Mesh) |
Wire diameter(mm) | Rotating speed of crank shaft (r/minute) |
Motor power(KW) | Weight(T) | Outside size(mm) | |
| ZWJ1300B | 1300 | 60-350 | 0.01-0.14 | 72 | 2.2KW380V,50HZ | 3.25 | 2650x2900x1300 |
| ZWJ1300D | 1300 | 16-120 | 0.14-0.30 | 72 | 2.2KW380V,50HZ | 3.25 | 2650x2900x1300 |
| ZWJ1600B | 1600 | 60-350 | 0.01-0.14 | 72 | 2.2KW380V,50HZ | 3.25 | 2650x2900x1300 |
| ZWJ1600D | 1600 | 16-120 | 0.14-0.30 | 72 | 2.2KW380V,50HZ | 3.25 | 2650x2900x1300 |
| ZZWJ-1300/1600 Heavy machine | 1300/1600 | 2-16 | 0.1-0.55 | 35 | 5.5KW380V,50HZ | 8-16 | 3500x4200x2500 |
| ZZWJ-1300/1600 BIG Heavy machine | 1300/1600 | 2-20 | 0.5-1.6 | 35 | 5.5KW380V,50HZ | 8-16 | 3500x4200x2500 |
| Above is just as your reference tell us the mesh, wire diameter, width which you frequently weave in whole year We will make the machine based on this, then it will save you cost: machine purchasing cost, material weaving waste cost, power consumption cost | |||||||
| For the Mesh width you weave , we not only do 1300 /1600, we also can do 1000, 2000, 3000, 4000, it is based on your request | |||||||
|
Different country, the power pressure is different, like India–415V or 440-220 V So this is adjustable by your country’s need | |||||||
| What we focus on is detailed and real request, then it will be helpful for us to give our best valued suggestion | |||||||
