Help CenterAlucoone Signboad Aluminum Composite Panel
Related Products
-
Alucoone Unbreakable Aluminum Composite PanelUS$ 6.05 - 6.55MOQ: 500 Square Meters -
Alucoone Mirror Finished Aluminum Cladding Panel Composite PanelUS$ 8.5 - 9.2MOQ: 500 Square Meters
-
Copper Composite Panel Alucoone SupplierUS$ 67.58 - 67.88MOQ: 1000 Square Meters
-
Zinc Composite Panel Alucoone SupplierUS$ 68.23 - 68.55MOQ: 1000 Square Meters
-
Supper Thinckness and Width Composite Panel Alucoone SupplierUS$ 12.19 - 12.35MOQ: 1000 Square Meters
1)Material:
A) front : aluminium alloy sheet coated with high quality polyestor resin(PE), (Supplier:BEKCER ,PPG).
B) core: nontox low density polyethylene
C) back: aluminium alloy sheet coated with polyester resin painting
D) surface coating thickness: 16μ±1μ
E) aluminium alloy: 3003 H24
F) sheet thickness: 0.12mm,0.15mm,0.21mm,0.3mm
2)Dimensions
A) thickness: 2mm, 3mm, 4mm, 6mm, 8mm,10mm
B) widthe: 1220mm( 2000mm max)
C) length: 2440mm,3050mm,4050mm( max:6000mm)
D) weight: 3.98kg/sqm baesd on 0.3/3mm thickness
E) standard size:1220*2440mm
F) qty/20'fcl: 3000m² ~5000m²
G) non-stanard size are available according to requirement
4)Features:
A) Light weight,flat surface and high strength
B) Excellent heat insulation ,sound insulation,fire-resistance,acid-resistance,alkali-resistance,weatherproofness and non-resonance
C) Various uniform colors
D) Rbright ,elegan and magnificent,fit for various designs
E) Kynar 5000 PVDF resin feature strong chemical resistance,unique colors can be easily maintained
5)Applications:
A) May be widly used in gallaies,exhibition,saloons,stores,offices,banks,hotels,restaurants and apartments
B) An ideal decorative materials for buildings
C) An ideal outer and inner walls
D) Kitchen cabinees,billboards,signboards,tunnels,subway,interiors
E) Cellings,eaves,galleries,balconies,partitions,interior decorations
F) Telephone tooths,vehicle bodies,yachts,industrial usage etc.
f
6) Packing:Put all the panles in one wooden box. Stocks: the packings are less 6 per one pile.Loading the container time, we will use timbers to reinforce.
