Customized Ceramic Rollers for Glass Tempering Furnace
US$ 1 - 500
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Lever
Place of Origin:
China
Model Number:
LV-CR
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
30 days
Related Products
-
Ceramic Rollers on Glass Tempering MachineUS$ 1 - 100MOQ: 1 Piece -
Fiber Ropes Used on Glass Tempering Furnace 12x4mmUS$ 1 - 100MOQ: 1 Roll
-
Kevlar Ropes Used on Glass Tempering FurnaceUS$ 1 - 100MOQ: 1 Roll
-
Diamond Core Drill Bits for Glass DrillingUS$ 1 - 100MOQ: 1 Piece
-
Diamond Core Staight Shank Drill Bits for Glass DrillingUS$ 1 - 100MOQ: 1 Piece
Brand Name
Lever
Place of Origin
China
Model Number
LV-CR
Ceramic rollers for Glass Tempering furnace
Application
Fused silica ceramic roller is ideal substitute for graphite rolls and ceramic coating rolls, prevent oxidation and dross build-up, carrying and transmitting glass in glass horizontal tempering furnace and annealing kilns.
Brief Introduction:
Fused silica ceramic roller adopts fined high purity fused silica as raw material and made by foreign advanced grouting molding technique and processing manufacturing line.
Molding methods mainly are grouting and gel injection molding, dry pressing and cold isostatic pressing. We can produce big size of fused silica ceramic roller by these methods.
There are end caps and end shafts, usually made of metal, tightly connected at both ends of ceramic rolls.
In the solar energy industry, the service temperature is about 1150C. In glass industry, the Service temperature: about 900C.
Brief Introduction:
Fused silica ceramic roller adopts fined high purity fused silica as raw material and made by foreign advanced grouting molding technique and processing manufacturing line.
Molding methods mainly are grouting and gel injection molding, dry pressing and cold isostatic pressing. We can produce big size of fused silica ceramic roller by these methods.
There are end caps and end shafts, usually made of metal, tightly connected at both ends of ceramic rolls.
In the solar energy industry, the service temperature is about 1150C. In glass industry, the Service temperature: about 900C.
Our Advantages
1. Raw material with high purity, excellent chemical and physical properties
2. Good surface smoothness, not easy to scratch glass
3. High density without bubbles
4. Very High Compressive Strength, Flexural Strength & Impact Strength at high temperature.
5. Good wear resistance
6. Small radial beat (run)
7. Very low thermal expansion coefficient
8. Strong thermal shock stability
9. High precision in size
10. No deformation under high temperature
11. Long service life, The reliable axle neck joint technology(anti-loose technology)
12. No pollution to glass
13. High economic efficiency, can reduce the overall cost of belt conveyer, reduce maintenance working hours
2. Good surface smoothness, not easy to scratch glass
3. High density without bubbles
4. Very High Compressive Strength, Flexural Strength & Impact Strength at high temperature.
5. Good wear resistance
6. Small radial beat (run)
7. Very low thermal expansion coefficient
8. Strong thermal shock stability
9. High precision in size
10. No deformation under high temperature
11. Long service life, The reliable axle neck joint technology(anti-loose technology)
12. No pollution to glass
13. High economic efficiency, can reduce the overall cost of belt conveyer, reduce maintenance working hours
Technical Data /
Ceramic Characteristics /
1. Typical Composition /
| Name | Specification | Remark |
| Silica / SiO2 | ≥ 99. 8% | |
| Alumina/ Al2O3 | ≤ 2000ppm | |
| Iron Oxide / Fe2O3 | ≤ 45ppm | |
| Copper Oxide / Cu O | ≤ 45ppm | |
| Titania / TiO 2 | ≤ 45ppm | |
| Chromium Oxide / Cr 2 O3 | ≤ 45ppm | |
| Nickel Oxide / Ni O | ≤ 45ppm | |
| Magnesia / MgO | ≤ 40ppm | |
| Sodium Oxide / | ≤ 40ppm | |
| Potassium Oxide / K 2 O | ≤ 40ppm |
2. Physical Properties / Density / :2. 00 g/cm3
| Name | Specification | Remark |
| Run out/ : | ||
| Roughness/ : | ||
| Apparent porosity /: | ||
| Compressive Strength /: | > 50Mpa | |
| Modulus of Rupture /: | >20MPa | |
| Crystallinity /: Crystobalite |
3. Thermal Properties /
| Thermal Conductivity / : 20°C: | 0. 64 | W/m°K |
| 500 °C: | 0. 81 | W/m°K |
| 1090°C: | 0.88 W/m°K | |
| Expansion Coefficient / | 20 °C – 1000 °C : 0.6 x 10 -6 /°C | |
| Max Use Temperature (a single thermal cycle) / : |
16 50 °C :1100 °C |
|
| Melt point / : | 1750 °C | |
4. Surface Quality /
| Name | Specification | Remark |
| Dimensions Tolerance Unmarked / | :≤± 2mm. | |
| Flatness: Diamond finishing, convex /concavity / : |
≤± 0. 2mm. |
|
| Ceramic does not have crack, corner /edge spalling, and opening bubbles. | ||
Note: These values are not warrant for products and system. They represent only standard material. They may also change because of continuous technology innovation.
Lever Industry Co have more than 19 years of experience in the Glass Machine Industry.
We are Unremitting, Just for Customer Satisfication!
| Contact Person : | Mr. Kevin |
| Job Title : | Sales Director |
| WHATSAPP : | +86 136 5379 2967 |
| Skype : | glasstempering |
| Email : | sales@leverglass.com |
| Website: www.ur-brand.net www.ur-brand.net www.ur-brand.net | www.leverglass.com |
