CNC Busbar Machine, Busbar Bending Machine, Busbar Punching Machine, Busbar Cutting Machine
US$ 1 - 1
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
KIANDE
Place of Origin:
China
Model Number:
CXJ
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
45 days
Related Products
-
Busbar Punching MachineNegotiableMOQ: 1 Set -
Busbar Film Forming Machine for Busabr Isolation Wrapping FilmNegotiableMOQ: 1 Set
-
Hydraucli Busbar Punching Machine for Busbar Bending and CuttingNegotiableMOQ: 1 Set
-
Busway Assembly Machine,Busbar Machine For Sandwich Busduct AssmeblyUS$ 1 - 1MOQ: 1 Set
-
Automatic Busbar Fabrication Equipment For 2 Piece Type Busbar Clamp And RivetingUS$ 1 - 1MOQ: 1 Set
Brand Name
KIANDE
Place of Origin
China
Model Number
CXJ
Three in one copper bar cutting bending punching machine
Features:
1) Double-column shearing structure, no scraps and shear droops
2) Workstation of punching adopts single-arm type integral structure
3) PLC control.
4) Hydraulic rubber hose adopts nationalstandard A type connection mode
Technical parameters:
| Nominal pressure | 300KN | 300KN |
| Max. working size | 12x160mm | 12x160mm |
| Punching range | Ø4.3-25mm | Ø4.3-25mm |
| Max. vertical bending working width | 120mm | 120mm |
| Work bench size | 1400x1000mm | 1400x1000mm |
| Boundary dimension | 1500x1150x1170mm | 1500x1150x1170mm |
| Weight | 1270kg | 1170kg |
