Name: China CNC Double Head Plastic Window Frame Cutting Machine with CE LJZ2-CNC-450X3700
Model: LJZ2-CNC-450X3700
Function:
This door and window making machine is the cnc double mitre saw which is used for not only aluminum profile cutting, but also corner connector cutting.
The two-way location-and-clamping feature high precision and steadiness.
Auto-opening guard shield ensured safety operation.
Uniform sped feeding and smooth motion due to air-Hydraulic damping cylinder.
The Schneider Electric Parts and Easun Pneumatic Parts are installed on this cnc double mitre saw.
Saw blade rotate smoothly due to high accuracy main spindle.
Imported linear bearing motion pair ensured steady processing accuracy.
Imported carbide saw blade give accurate processing and high endurance.
45°and 90°cutting is available. 22.5° is optional angle.
Adopted DELTA CNC technique, can achieve various profile auto cutting off.
Adopted high helical pitch ball screw-lead motion, with high accurate driving, locating and smooth working.
Feeding system adopts imported linear guide pair, with high accuracy and long service life.
The cnc double mitre saw is suitable for batch production.
| Series No. | Techncial Item | Technical Parameters |
| 1 | Power Supply | 380V 50Hz 4.4Kw |
| 2 | Air Pressure | 0.5-0.8Mpa |
| 3 | Saw Blade Specification | 450*30mm |
| 4 | Saw Blade Rotation Speed | 2800RPM |
| 5 | Cutting Scope | 580-3700mm |
| 6 | Cutting Angle | 45 degree/ 90 degree |
| 7 | Overall Dimension | 5000*1400*1650mm |
| 8 | Total Weight | 1600Kg |
China CNC Double Head Plastic Window Frame Cutting Machine with CE
China CNC Double Head Plastic Window Frame Cutting Machine with CE LJZ2-CNC-450X3700
--DELTA Touch Screen
China CNC Double Head Plastic Window Frame Cutting Machine with CE LJZ2-CNC-450X3700
--MITSUBISHI System
China CNC Double Head Plastic Window Frame Cutting Machine with CE LJZ2-CNC-450X3700
--ABBA Lead Screw
China CNC Double Head Plastic Window Frame Cutting Machine with CE LJZ2-CNC-450X3700
--DELTA Control System
China CNC Double Head Plastic Window Frame Cutting Machine with CE LJZ2-CNC-450X3700
--High Quality Pneumatic Parts
+ Package type: Wooden Case and Wooden Pallet.We do not suggest using the plastic cover only on our machines.
+ Shipping type: Sea transportation and Express transportation. We do not suggest using the land transportation.
Our senior engineer is available to travel aboard, help the installation, maintenance and training staff.
We have our own spare parts warehouse for window door machines and insulating glass machines.
We can reply for every customers within 24 hours.
By offering this support, we make sure the cutomer start the business smoothly, to realise win-win cooperation.
CCI always looking for long term cooperaion, not one time deal.
As a path breaker in windoor machines of China, CCI Group creates and develops the brand-new high quality window machines and Insulating Glass Machines with 23 years hard working. Our aim is the best windoor machines and insulating glass machines manufuctuer from China.
Attaching much importance to quality and taking management and technology development as the impetus, CCI Group tacks the culture of operation excellence, and has obtained ISO9001-2000 edition and CE Qualification successively.
So far CCI Group has more than thirty offices around China, and has built many a foreign office, such as in Canada, Kazakstan, Vietnam and etc.
Now CCI Group has become the all-around equipments manufacturer, producing more than one hundred products, which includes UPVC Window Door Making Machines, Aluminum Window Door Making Machines , Aluminum Curtain Wall Processing Machine and Insulating Glass Processing Machines.
We would like to expand our cordial cooperation with you for better future.
CCI Factory CE Certificate on year 2002
+ Most of pvc window making machines were passed CE Certificate;
+ Most of insulating glass making machines were passed CE Certificate;
+ Several aluminium window making machines were passed CE Certificate.
CCI Factory Exhibition Photo
+ As you known, our factory has several oversea offices all over the world. Normally, our marketing manager and distributor join the local market exhibition by ourselves.
+ If you have chance to be together with us on exhibition, welcome to contact us our marketing manager face to face if you have any demand about machine or after service for machines.
CCI Factory details:
+ Our factory has two large fabricating factories;
+ Our factory has our own office building and staff apartment;
+ Our factory has 25 fabricating workers which have more than 10 window door and insulating glass fabricating experience;
+ Any more details, welcome to contact us our customer service department at any time on line.
CCI Factory Customer Details:
+ Our factory export our machines to more than 57 countries and areas.
+ Here we make a simple introduction about our client countries: USA, Canada, Brazil, Russia, Ukraine, Turkey, India, Pakistan, Vietnam, Philippines, Cambodia, Tunis, Nigeria and so on.
+ Hope you can be the next client in near future.
CCI is the best choice you can choose.
A. Question: What kind of our company is CCI?
Re: CCI is window door machines and insulating glass machines manufacturing exporter since year 1991. We passed CE european standard on year 2002.
B. Question: How is China CNC Double Head Plastic Window Frame Cutting Machine with CE LJZ2-CNC-450X3700 guarantee?
Re:
b1. China CNC Double Head Plastic Window Frame Cutting Machine with CE LJZ2-CNC-450X3700 warrenty period is 24 months after BL time;
b2.12 hours technical support feedback;
b3. Own window factory supply window fabrication support;
b4. Own machining factory, which can control the spare parts quality at high quality;
b5. Own accessories warehouse and user can enjoy the agent price.
C.Question: How is delivery time?
Re: We can delivery the machines within 7 days if we have the machines in stock.
The common machine fabricating time is 3-7 days and CNC machine fabricating time is about 7-12 days.If you have customized products, the delivery time will be given after confirmation.
D. Question: How is payment?
Re: 30% of amount as deposit and the balance should be paid by T/T or LC at sight before seller delivery the machines to loading port.
E.Question: How is our package?
Re: Wooden Pallet/ Wooden Case. In order to ensure high quality products precision, the perfect package is necessary.
F. Question: Why is price higher than other supplier?
Re: f1. We have our own machining factory and the high quality technical quality is our aim;
f2. All the electric parts and pneumatic parts are high quality. Most of them are imported from european and american market;
f3. Most of fabricating worker has more than 10 years working time. Their fabricating work is professional and salary is higher;
f4. Our warrenty period is 24 months after BL time. It can support the new comer client going well in the beginning time.
